Features

  • Bring your business together with Edge LED technology, slim bezel, enhanced user experience and a brightness sensor.

Brightness Sensor

Brightness Sensor
The new UE Series LED LFD screens come a brightness sensor that detects the ambient light instensity and automatically adjusts the screen brightness.

Enhanced User Experience

Enhanced User Experience
Samsung LFDs leverage the most cutting-edge technology to provide enhanced functionality aligned to your business needs. With the built-in media player for your Samsung LFD, you can activate your display capabilities more than you ever thought possible. Built within a microchip the media player has a CPU with a powerful processing speed of 800MHz and an impressive cache size of 512KB. The inclusion of our Samsung MagicInfo Lite software enables you to run the LFD as a stand alone unit without the need of additional players.

Reduced heat

Reduced heat
Optimise the conditions of your digital signage by reducing the amount of heat radiating through the actual display area. Conventional LFDs emit consistent amounts of heat across the breadth of the display, while the new Samsung LFD not only minimise it but centralise it around the sides of the screen. This proves helpful in creating a more enjoyable environment to be in, especially when working in close proximity to the displays, like at a business convention.
Edge LED Technology

Edge LED Technology

Samsung Edge LED solution utilises LED lamps around the edge of the panel so the LEDs emit light on the side of the panel. This results in a much thinner screen that requires fewer lamps meaning reduced power consumption and less heat generation. Its slim and light weight design offers heavy weight communication solutions for any business looking to convey concise marketing or educational messages. Plus low power consumption means lower running costs. The LED technology driving the LFD consumes less energy than conventional CCFL-based LFD and is lower on co2 emissions.
Best Solution For Your Video Wall

Best Solution For Your Video Wall

Samsung is changing the look, cost, and longevity of video display walls. At 10.44mm in thickness, the bezel for the Samsung UE Series has been designed to maximise viewing experience. The slim bezel removes any distraction from your sight to provide a greater surface area. The UE Series also utilises Edge-Type LED, allowing it to be much slimmer than the competition.
Reliable Digital Signage Display

Reliable Digital Signage Display

Our extensive range of LFDs produces astonishing advertising solutions when used to create increasingly popular Digital Information Displays. The displays’ advanced features and widest variety of sizes will ensure reliable performance while making a compelling impact on your audience. The ultra-narrow bezels result in a superior visual experience, and they are specifically designed for both indoor and outdoor use thanks to airtight casing that protects them from dust, humidity and high temperatures.

tech specs

Display

  • H-Scanning Frequency

    30 - 81 KHz

  • Maximum Pixel Frequency

    148.5 MHz

  • V-Scanning Frequency

    48 - 75 Hz

Panel

  • Diagonal Size

    46"

  • Type

    240 Hz LED BLU

  • Resolution

    1,920 x 1,080

  • Pixel Pitch(mm)

    0.15375 mm (H) X 0.46125 mm (V)

  • Active Display Area

    1018.08 mm (H) X 572.67 mm (V)

  • Brightness

    450 cd/㎡

  • Contrast Ratio (Dynamic)

    100,000:1 (AV Mode)

  • Viewing Angle (Horizontal/Vertical)

    178 / 178 ° (CR > 10)

  • Response Time (G-to-G)

    8 ms

  • Display Color

    10bit Dithering - 1.07 Billion

  • Color Gamut

    73 %

  • Contrast Ratio

    5,000:1

SHOW MORE SPECSExpand

Connectivity

  • Input
    RGB

    Analog D-SUB, DVI-D, Display Port

    Video

    Component (CVBS Common), HDMI

    AUDIO

    Stereo mini Jack

  • Output
    RGB

    DVI-D

    Video

    N/A

    AUDIO

    Stereo mini Jack

    Power Out

    N/A

  • External Control

    RS232C (In/Out) thru Stereo Jack, RJ45

  • External Sensor

    N/A

Mechanical Specification

  • Dimension
    Set Dimension (WxHxD)

    1,030.4 X 585.0 X 29.9 mm

    Package Dimension (WxHxD)

    1,170.0 X 705.0 X 199.0 mm

  • weight
    Set Weight

    12.0 kg

    Package Weight

    15.9 kg

  • VESA Mount

    400 x 400 mm

  • Protection Glass

    N/A

  • Stand Type

    Foot Stand (Optional)

  • Media Player Option Type

    Embedded

Operation

  • Operating Temperature

    0 - 40 ℃

  • Humidity

    10 - 80 %

General Feature

  • Key

    LED Slim Video wall

  • Special

    Built in MagicInfo Lite, Built in Speaker (10W + 10W), Plug and Play (through USB), Narrow Bezel, Slim Depth (29.9,mm), Video Wall(10x10)

Power

  • Energy Efficiency Class

    N/A

  • Power Supply

    AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

  • Power consumption
    Off Mode

    less than 1 W

    On Mode

    150 W (Max) / 125 W (Typ)

    Sleep Mode

    less than 1 W

  • Type

    Internal

Embedded PC

  • CPU

    N/A

  • N/B

    N/A

  • S/B

    N/A

  • GPU

    N/A

  • FDM/HDD

    N/A

  • Memory

    N/A

  • Ethernet

    N/A

  • Connectivity
    USB

    N/A

    Output

    N/A

    Others

    N/A

Certification

  • EMC

    FCC (USA) FCC Part 15, Subpart B class ACE (Europe) EN55022, EN55024VCCI (Japan) V-3 (CISPR22)KCC (Korea) :KN22, KN24BSMI (Taiwan) : CNS13438 (CISPR22)C-Tick (Australia) : AS/NZS3548 (CISPR22) CCC(China) :GB 9254-2008, GB 17625.1-2003

  • Environment

    ENERGY STAR 5.0 (USA)

  • Safety

    cUL (USA+Canada) : UL60065 TUV (Germany) : EN60065CB (Europe) : IEC60065/EN60065EK (Korea) : K60065 CCC (China) : GB8898PSB (Singapore ) : IEC60065 GOST (Russia ) : IEC60065, EN55022 SIQ (Slovenia ) : IEC60065, EN55022 PCBC (Poland ) : IEC60065, EN55022 NOM (Mexico ) : NOM-001-SCFI-1993IRAM (Argentina ) : IRAMSASO (Saudi Arabia ) : IEC60065

Accessory

  • Included

    Quick Setup Guide, Warranty Card,Application CD, D-Sub cable, Power Cord,Remote Controller, Batteries

  • Optional
    Mount

    WMN4270SD, WMN2000BD, WMN4655MD(for Video wall W/M)

    Specialty

    CML450D (Ceiling Mount)

    Stand

    STN-L4055AD
