Samsung
Product Features
Matrix Video Wall
Matrix Display for Video Wall.
Built-In Image Enlarging Processor supports various video wall formats. If user wants to install Video Wall as these formats, user doesn't need any other Video Controller Device. Also if viewer uses video & PC Interface, additional Input Signal Distributor is not necessary.
2 Way Multi Display format.
In the case of Multi Display video wall, a major issue is how to display naturally without picture distortion. So Samsung's New Plasma Monitor supports two types of video wall formats. The first is Full mode which displays the picture regardless of cabinet bezel. The second, Natural Mode, considers bezel's depth when displaying picture.
Pivot Technology
Flexible Pivot Function that freely rotates around 90˚ degrees, allowing you to easily View a vertical image or text without mouse scrolling. This function gives you more flexibility, supporting presentations in portrait mode.
Specifications
Display
Screen Size
- 40"
Resolution
- 1920 x 1080
Display
Viewing Angle (Horizontal/Vertical)
- 178° / 178°
Signal Input
Video Signal
- Analog RGB, DVI-D, CVBS, HDMI
Sync. Signal
- Separate H/V, composite, SOG
Connector
- D-Sub, RS232C cable
Features
Plug & Play
- DDC 2B
Multimedia Speakers
- 10 watts x 2ch (Built-in)
Special Features
- Lamp Error Detection, Matrix Video Wall (2 x 2, 3 x 3, 4 x 4, 1 x 5, 5 x 1, 5 x 5), Safety Lock, Temperature Sensor, Built in Fan, RS232C
Mac compatibility
- Yes
Panel
Brightness
- 450cd/m²
Contrast Ratio
- 4,000:1
Response Time (G-to-G)
- 8ms (GTG)
Panel
Display Color
- 16.7Mil.
Power
Power consumption
- 290 watts
Stand-by Power (DPMS)
- < 5 watts (Energy Saving ON)
