460MX-3

460MX-3

Imagine people paying greater attention to your information. Whether it’s the classroom or the boardroom, the Samsung 460MX-3 46" LFD display can help. SAMSUNG S-PVA panel technology, HDMI input, 1080p Full HD support and built-in speakers make sure your message is seen as well as heard. And for even more impact, you can use the supplied Multi Display Control software and RS-232C interface to create huge video walls in configurations up to 10 by 10.

Recycling Batteries Responsibly

  • The European Directive on Batteries and Accumulators aims to minimise the impact of batteries on the environment and encourage the recovery of the materials they contain. In the UK, regulations on the recycling of batteries and accumulators (rechargeable batteries) were Introduced in 2009. The Waste Batteries Regulations aim to significantly increase UK collection and recycling of used portable batteries from 3% in 2007 to 25% by 2012, rising to at least 45% in 2016.

  • The battery symbol on a product or on its packaging indicates that the product must not be disposed of with general household waste. Instead, it is the consumer’s responsibility to dispose of their waste batteries at a designated collection point so that they can be recycled. The separate collection and recycling of batteries at the time of dispo sal will help to conserve natural resources and ensure that they are recycled in a manner that protects human health and the environment. A comprehensive list of battery recycling centres can be obtained from: www.recycle-more.co.uk

  • All Samsung products that are subject to the Batteries Directive are compliant with the UK battery and accumulator Requirements. In accordance with national law, SAMSUNG Electronics (UK) Ltd is a member of an approved batteries producer compliance scheme. This scheme collects, treats and disposes of batteries on Samsung’s behalf.

460MX-3

Features

  • 46" Professional LFD display

Enhanced connectivity without extra costs.

Enhanced connectivity without extra costs.
Create a professional digital display without having to purchase any extras—like a distributor or external equipment. Samsung makes it easy with a display port that delivers enhanced connectivity and an improved display interface. With a simple adapter, you can connect your PC, monitor or TV using an HDMI or DVI cable that’s more than twice as long as standard cables. Discover an easy, cost-effective way to create a powerful display.

Easy control goes the distance.

Easy control goes the distance.
With content constantly changing, you need a reliable software solution that lets you communicate with remote displays in a cost-effective, time-efficient manner. Samsung LFDs feature an upgraded Multi Display Control solution that lets you control a large number of monitors through their embedded RS232 and RJ45 interfaces. Easy and intuitive to use, you can control monitors over short and long distances.

Set a schedule that’s always on time.

Set a schedule that’s always on time.
Keep your monitor running efficiently at all times. This Samsung LFD boasts a smart scheduling feature. The automatic power on/off function allows you to designate time, day, volume, input source and holiday dates. There’s even a convenient on-screen display setting with up to 3 schedules including day and time.

A video wall that lives up to your standards

 A video wall that lives up to your standards
Create the ultimate video wall with Samsung LFDs that cater to your needs. And because this LFD has an embedded video matrix processor, it supports 1x1 to 10x10 wall formats, allowing you to enjoy total convenience. Best yet, since they need no additional support, the possibilities are almost endless.

Save money, save space with built-in speakers.

Save money, save space with built-in speakers.
Maximize your impact with a great picture and crisp audio. Your message will be heard loud and clear with built-in speakers. You’ll save money when you eliminate the cost of purchasing separate speakers, and you’ll save valuable space as well.

A cool way to ensure longevity.

A cool way to ensure longevity.
Enjoy continuous, reliable operation thanks to a built-in fan control. Housed inside of the LFD, the fan guarantees you can count on it for years to come without worrying about it overheating. You can even control the fan with an easy-to-use on screen display.

Choose the right view, landscape or portrait.

Choose the right view, landscape or portrait.
This Samsung LFD gives you the flexibility to display your image vertically or horizontally—whatever the situation calls for. With a pivot function that rotates the screen 90˚degrees and the freedom to display presentations in portrait mode or advertisements in landscape mode, this makes for one versatile monitor.

Twice the information, double the impact.

Twice the information, double the impact.
Whether your presentation requires a picture-in-picture configuration or a picture-by-picture arrangement, this Samsung LFD makes it possible. When one image just isn’t enough, two video signals can be viewed simultaneously for maximum impact.

A screen that won’t shatter your digital dreams. (option)

A screen that won’t shatter your digital dreams. (option)
When a monitor is displayed in public areas, things can happen. That’s why our LFD offers a specially-designed, optional protection glass. Scratch resistant and shatter-proof, it shields the panel’s surface from any damage so you can use it for years to come.

A great picture that’s glare-free.

A great picture that’s glare-free.
Whether you have a story to tell or a product to sell, it’s important that your image is crystal clear. This Samsung LFD delivers just that—even if your display is located in a brightly-lit environment. It eliminates any reflections that can disrupt your ad’s readability, keeping images smooth and visible.

A slide-in design with easy accessibility.

A great picture that’s glare-free.
Enjoy convenient, quick access to the PC, network or receiver with this LFD’s optional slide-in modular design. It’s discreetly located on in the rear side of the unit. And there are a variety of module options that can be easily combined with the LFD. You can even insert a customized module—whether it’s Samsung or a third party manufacturer.

Upgrade effortlessly.

Upgrade effortlessly.
This Samsung LFD LFD makes upgrading firmware easy. The simple transmission is accomplished through an image file, using a DVI, HDMI or display port. Samsung’s LFD LFD lets you perform upgrades effortlessly through a direct connection with your PC.

tech specs

Panel

  • Diagonal Size
    46"
  • Contrast Ratio (Dynamic)
    10000:1
  • Type
    S-PVA( B-DID)
  • Resolution
    1920 x 1080(16:9)
  • Pixel Pitch(mm)
    0.53025(H) * 0.53025(V)
  • Active Display Area
    1018.08(H) x 572.67(V)
  • Brightness
    450cd/m2
  • Contrast Ratio
    3000:1
  • Viewing Angle (Horizontal/Vertical)
    178/178
  • Response Time (G-to-G)
    8ms
  • Display Color
    8 bit - 16.7M
  • Color Gamut
    72%

Display

  • H-Scanning Frequency
    30kHz ~ 81kHz
  • V-Scanning Frequency
    56Hz ~ 85Hz
  • Maximum Pixel Frequency
    148.5MHz

SHOW MORE SPECSExpand

Connectivity

  • Input
    RGB
    Analog D-SUB, DVI-D, Display Port
    Video
    CVBS, HDMI1,HDMI2, Component(D-sub 15pin)
    AUDIO
    RCA(L/R) , Stereo mini Jack
  • Output
    RGB
    N/A
    Video
    N/A
    AUDIO
    Stereo mini Jack
    Power Out
    5V (for SBB)
  • External Control
    RJ45, RS232C(in/out)
  • External Sensor
    N/A

Power

  • Type
    Internal
  • Power Supply
    AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
  • Power consumption
    On Mode
    260W(max) / 233W(typ)
    Sleep Mode
    less than 2W
    Off Mode
    less than 1W

Mechanical Specification

  • Dimension
    Set Dimension (WxHxD)
    1102 X 658 X 125.5
    Package Dimension (WxHxD)
    1220 X 780 X 310
  • weight
    Set Weight
    22.8
    Package Weight
    29.8
  • VESA Mount
    600 x 400 mm
  • Protection Glass
    Optional
  • Stand Type
    Foot Stand(optional)
  • Media Player Option Type
    SIM (Slide in Module )

Operation

  • Operating Temperature
    0℃~ 40℃
  • Humidity
    10~80%

General Feature

  • Key
    Economy and Reliability
  • Special
    Lamp Error Detection, Anti Retention, Temperature Sensor, RS232C/RJ45 MDC,Built in Speaker (10W + 10W),Plug and Play (DDC2B), PIP/PBP, Video Wall(10x10), Pivot Display, Button Lock, Smart Scheduling, Smart F/W update

Certification

  • Safety
    UL (USA) : UL 60950-1CSA (Canada) : CSA C22.2 No. 60950-1 TUV (Germany) : EN60950-1NEMKO (Norway) : EN60950-1 KC (Korea) : K60950-1 CCC (China) : GB 4943-2001PSB (Singapore) : IEC60950-1GOST (Russia) : IEC60950-1, EN55022SIQ (Slovenia) : IEC60950-1, EN55022PCBC (Poland) : IEC60590-1, EN55022NOM (Mexico) : NOM-019-SCFI-1993IRAM (Argentina) :IEC60950-1SASO (Saudi Arabia) : IEC60950-1
  • EMC
    FCC (USA) FCC Part 15, Subpart B class BCE (Europe) EN55022, EN55024VCCI (Japan) V-3 (CISPR22)KCC (Korea) :KN22, KN24BSMI (Taiwan) : CNS13438 (CISPR22)C-Tick (Australia) : AS/NZS3548 (CISPR22) CCC(China) :GB 9254-2008, GB 17625.1-2003
  • Environment
    ENERGY STAR 5.0 (USA)

Accessory

  • Included
    Quick Setup Guide, Warranty Card,Application CD, D-Sub cable, Power Cord,Remote Controller, Batteries
  • Optional
    Stand
    STN-L3255D
    Mount
    WMN5770D
    Specialty
    CML500D(ceiling mount), STN-520WE(welcome Board)

Embedded PC

  • CPU
    N/A
  • N/B
    N/A
  • S/B
    N/A
  • GPU
    N/A
  • FDM/HDD
    N/A
  • Memory
    N/A
  • Ethernet
    N/A
  • Connectivity
    USB
    N/A
    Output
    N/A
    Others
    N/A

Support

User Manual

5.72 MB, pdf, ARABIC

2012.01.30

Other Manuals (4)

Driver (1)

  • Device(Install)(460MX-3 driver)

    Win 98/ME/2K/XP/X64/Vista/Vista 64/Win7/Win7 64, 7.9 MB, exe, MULTI LANGUAGE

    2010.12.14 tooltipbox

    Close tooltip pop-up
    1. Title
    Monitor Driver
    2. Applicable Model
    SyncMaster 460MX-3
    3. Carrier or Corporate Customer
    Open Market
    4. Description
    If you have trouble for setting up the Monitor under Windows 98/Me/2000/XP/X64/Vista/Vista64, this program will help you to install Windows Monitor Driver. You can install the most suitable Windows driver for your monitor.

    System Requirements : Windows 98/Me/2000/XP/X64/Vista/Vista64 /Windows7(32bit/64bit)
