Max R22 12 000BTU

AQ12UGQN

Max R22 12 000BTU   0 5 0 reviews

Recycling Batteries Responsibly

  • The European Directive on Batteries and Accumulators aims to minimise the impact of batteries on the environment and encourage the recovery of the materials they contain. In the UK, regulations on the recycling of batteries and accumulators (rechargeable batteries) were Introduced in 2009. The Waste Batteries Regulations aim to significantly increase UK collection and recycling of used portable batteries from 3% in 2007 to 25% by 2012, rising to at least 45% in 2016.

  • The battery symbol on a product or on its packaging indicates that the product must not be disposed of with general household waste. Instead, it is the consumer’s responsibility to dispose of their waste batteries at a designated collection point so that they can be recycled. The separate collection and recycling of batteries at the time of dispo sal will help to conserve natural resources and ensure that they are recycled in a manner that protects human health and the environment. A comprehensive list of battery recycling centres can be obtained from: www.recycle-more.co.uk

  • All Samsung products that are subject to the Batteries Directive are compliant with the UK battery and accumulator Requirements. In accordance with national law, SAMSUNG Electronics (UK) Ltd is a member of an approved batteries producer compliance scheme. This scheme collects, treats and disposes of batteries on Samsung’s behalf.

Max R22 12 000BTU

Features

  • Ideal air for perfect coolness

Compact Size.

Compact Size.
Samsung's advanced technology continues to amaze by developing new compct air conditioners, which reduxedoverall size by at least 12% while maintaining perfoman. Now experience greater convenience in space and installation

Easy to use. Easy to master.

Easy to use. Easy to master.
Samsung’s ergonomic, innovative remote control was designed for everyone, whether you’re in the first grade or celebrating your 81st birthday. With bigger numbers, soft-touch buttons, an easy-view display and a comfy grip, you’re always in control. And its circular navigation keypad truly brings power to the people.

Enjoy Comfortable

Enjoy Comfortable
Enjoy Comfortable Air Conditioning with Less Energy. Samsung's high efficiency MAX air conditioner lets you enjoy coolness at minimal cost. Its unique Smart Saver function prevents unnecessary energy consumption and Good SleepnII controls the temperature so that you can sleep comfortably throughout the night. Now enjoy powerful cooling, stay comfortable, and spend less.

Cooler with Stronger Air Conditioning!

Cooler with Stronger Air Conditioning!
Enjoy exceptional cooling power with the Samsung Max Air Conditioner. Max cools the room faster with strong refreshing air that fills the room quickly. With the touch of a button, experience cool comfort.
Wake up in a good mood with Good Sleep.

Wake up in a good mood with Good Sleep.

Missing out on a good night’s sleep can mean bad news for your day. That’s why Samsung’s Good Sleep feature creates an ideally comfortable climate in your bedroom. With a precise temperature control system and automatic moisture adjustment, all three vital stages of your sleep is protected from humidity and heat so you wake up fully refreshed and ready to take on a new day. Good Sleep not only saves you precious minutes and hours of potentially lost sleep, it also saves up to 36% in energy consumption compared to the normal cooling mode.

tech specs

Dimension of AQ12UGQNXFA

Performance

  • Energy Efficiency
    EER (Cooling, Btu/W)

    9.23Btu/hW

    EER (Cooling, W/W)

    2.71W/W

    COP (Heating, W/W)

    3.28W/W

  • Moisture Removal (l/hr)

    1.5l/hr

  • Noise Level
    Indoor High/Low

    35 / 27dBA

    Outdoor High

    50dBA

Electrical Data

  • Power Source
    Φ/V/Hz

    1 Φ / 220 - 240V / 50Hz

  • Energy Efficiency
    Power Consumption (Cooling)

    1,300W

    Power Consumption (Heating)

    1,160W

    Operating Current (Cooling)

    6A

    Operating Current (Heating)

    5.5A

SHOW MORE SPECSExpand

Physical Specification

  • Dimension
    Net Dimension (WxHxD, Indoor)

    820 x 285 x 190mm

    Net Dimension (WxHxD, Outdoor)

    660 x 475 x 242mm

  • Weight
    Net Weight (Outdoor)

    26.0kg

    Shipping Weight (Indoor)

    10.4kg

    Shipping Weight (Outdoor)

    30.0kg

    Net Weight (Indoor)

    8.4kg

Technical Information

  • Refrigerant Type

    R22

  • SVC Valve
    Liquid (ODxL)

    Liquid 6.35mm x 5m

    Gas (ODxL)

    Gas 12.7mm x 5m

  • Piping Length
    Piping Length (Max)

    15m

  • Piping Height
    Piping Height (Max)

    7m

General Feature

  • Air Purification
    S-Plasma Ion

    No

    Auto Roof Shutter

    No

    Full HD Filter

    60

    DNA Filter

    No

    Deodorizing Filter

    No

    Catechin Filter

    No

    Allergy Care

    No

    Anti-Bacteria Coating

    Yes

    Auto Clean (Self Cleaning)

    Yes

  • Air Flow
    Wide Twin Blade

    No

    Optimal Single Blade

    Yes

    Air Flow Control Step (Cool/Fan)

    4 / 3

    Air Direction Control (Up/Down)

    AUTO

    Air Direction Control (Left/Right)

    MANUAL

    Natural Breeze

    Yes

  • Operating Mode
    Dlight Cool

    No

    Good Sleep

    Yes

    Smart Saver

    Yes

    Turbo Mode

    Yes

    Dehumidification

    Yes

    Auto Mode

    Yes

    Fan Mode

    Yes

    Quiet

    No

  • Convenience
    Indoor Temp. Display

    No

    Filter Cleaning Indicatior

    No

    Remote Controller

    Yes

    Display On/Off

    No

    Beep On/Off

    No

    Real-Time Timer

    No

    24-Hour Timer

    Yes

    Auto Restart

    Yes

    Auto Changeover

    Yes

  • Outdoor Unit
    Compressor Type

    UTR

    Anti-Corrosion Fin

    Yes

    Multi-Channel Condensor

    No

  • Low Ambient
    Cooling

    15 - 52°C

    Heating

    -5 - 24°C
