70'' 700DXn-2
Network LCD Display

700DXN-2

  0 5 0 reviews

Recycling Batteries Responsibly

  • The European Directive on Batteries and Accumulators aims to minimise the impact of batteries on the environment and encourage the recovery of the materials they contain. In the UK, regulations on the recycling of batteries and accumulators (rechargeable batteries) were Introduced in 2009. The Waste Batteries Regulations aim to significantly increase UK collection and recycling of used portable batteries from 3% in 2007 to 25% by 2012, rising to at least 45% in 2016.

  • The battery symbol on a product or on its packaging indicates that the product must not be disposed of with general household waste. Instead, it is the consumer’s responsibility to dispose of their waste batteries at a designated collection point so that they can be recycled. The separate collection and recycling of batteries at the time of dispo sal will help to conserve natural resources and ensure that they are recycled in a manner that protects human health and the environment. A comprehensive list of battery recycling centres can be obtained from: www.recycle-more.co.uk

  • All Samsung products that are subject to the Batteries Directive are compliant with the UK battery and accumulator Requirements. In accordance with national law, SAMSUNG Electronics (UK) Ltd is a member of an approved batteries producer compliance scheme. This scheme collects, treats and disposes of batteries on Samsung’s behalf.

70'' 700DXn-2 Network LCD Display

Features

  • 700DXN-2

A smart sensor that automatically saves energy.

A smart sensor that automatically saves energy.
Stop worrying about the lighting conditions affecting your display. This Samsung LFD adjusts its brightness levels as ambient light changes so your images are always crystal-clear. And while it compensates for low-light and high-light environments, you’ll save energy and stay eco-friendly.

Reliable, durable and dust-resistant.

Reliable, durable and dust-resistant.
Introducing a monitor that was built to stand the test of time—and dust. This Samsung LFD is durable and dust-resistant. Corner-sealing design, double-layer structure, and screw and user hole sealing add to its ruggedness. Make sure dirt and dust don’t stand in the way of getting your message out.

Save money, save space with built-in speakers.

Save money, save space with built-in speakers.
Maximise your impact with a great picture and crisp audio. Your message will be heard loud and clear with built-in speakers. You’ll save money when you eliminate the cost of purchasing separate speakers, and you’ll save valuable space as well.

A cool way to ensure longevity.

A cool way to ensure longevity.
Enjoy continuous, reliable operation thanks to a built-in fan control. Housed inside of the LFD, the fan guarantees you can count on it for years to come without worrying about it overheating. You can even control the fan with an easy-to-use on screen display.

Brighter lights, better picture.

Brighter lights, better picture.
With an intensely illuminated DID panel your message is always in the spotlight. Its high brightness and contrast level make the screen clear and readable in public. In fact, on average it’s 1.5 times as bright as TV screens. Plus with a low operating temperature this Samsung LFD will be completely reliable for years to come.

Choose the right view, landscape or portrait.

Choose the right view, landscape or portrait.
This Samsung LFD gives you the flexibility to display your image vertically or horizontally—whatever the situation calls for. With a pivot function that rotates the screen 90˚degrees and the freedom to display presentations in portrait mode or advertisements in landscape mode, this makes for one versatile monitor.

Stay in the loop with DVI-out.

Stay in the loop with DVI-out.
Enjoy superior picture quality with a DVI-out interface that lets you share content between multiple LFDs thanks to an easier-to-connect video matrix. LFDs used to have to be connected to the PC individually, but digital loop out allows you to connect them without connecting to a PC. Better yet, the digital loop out produces a single image without any loss of quality, and there’s no need for a separate video signal distributor. It’s easy to install and the most cost-effective way to connect multiple displays.

Twice the information, double the impact.

Twice the information, double the impact.
Whether your presentation requires a picture-in-picture configuration or a picture-by-picture arrangement, this Samsung LFD makes it possible. When one image just isn’t enough, two video signals can be viewed simultaneously for maximum impact.

An innovative solution with easy access.

An innovative solution with easy access.
Samsung’s network management software features two types: a Wan/Lan-based for local access and a web-based software accessible anywhere. MagicInfo™ lets you access your server and LFDs everywhere in the world. This optimised Samsung software solution lets you manage multiple Samsung LFDs remotely. Best yet, uploading, creating, monitoring and controlling content is more convenient and less time-consuming.

No separate PCs. No jumbled wires.

No separate PCs. No jumbled wires.
Control multiple monitors without having to install and run wires to a separate PC. This Samsung LFD features a powerful built-in PC. Its optional multi-network solution—purchased separately—is easy to configure through a LAN, easy to manage through server-side software, and cost-effective to run. And with optimised CPU, RAM and storage, you’ll have everything you need to get your message across effectively.

A screen that won’t shatter your digital dreams. (option)

A screen that won’t shatter your digital dreams. (option)
When a monitor is displayed in public areas, things can happen. That’s why our LFD offers a specially-designed, optional protection glass. Scratch resistant and shatter-proof, it shields the panel’s surface from any damage so you can use it for years to come.

A great picture that’s glare-free.

A great picture that’s glare-free.
Whether you have a story to tell or a product to sell, it’s important that your image is crystal clear. This Samsung LFD delivers just that—even if your display is located in a brightly-lit environment. It eliminates any reflections that can disrupt your ad’s readability, keeping images smooth and visible.

tech specs

Dimension of LH70BVSLBF/XY

Display

  • H-Scanning Frequency

    30kHz - 81kHz

  • Maximum Pixel Frequency

    148.5MHz

  • V-Scanning Frequency

    56Hz - 85Hz

Panel

  • Diagonal Size

    70"

  • Type

    S-PVA (DID)

  • Resolution

    WXGA 1920 x 1080 (16:9)

  • Pixel Pitch(mm)

    0.807 (H) x 0.807 (V)

  • Active Display Area

    1,549.44 (H) x 871.56 (V)

  • Brightness

    600cd/m²

  • Contrast Ratio (Dynamic)

    2,500:01

  • Viewing Angle (Horizontal/Vertical)

    178° / 178°

  • Response Time (G-to-G)

    8ms

  • Display Colour

    8 bit - 16.7M

  • Colour Gamut

    72%

  • Contrast Ratio

    2,000:01

SHOW MORE SPECSExpand

Connectivity

  • Input
    RGB

    Analog D-SUB, DVI-D, Display Port

    Video

    CVBS, HDMI1, HDMI2, Component (D-Sub 15 Pin)

    Audio

    RCA(L / R), Stereo mini Jack

  • Output
    Video

    BNC

    Audio

    Stereo mini Jack

    Power Out

    5V

  • External Control

    RJ45, RS232C (in / out)

Mechanical Specification

  • Dimension
    Set Dimension (WxHxD)

    1,668 x 990 x 138mm

    Package Dimension (WxHxD)

    1,850 x 1,231 x 630mm

  • Weight
    Set Weight

    83kg

    Package Weight

    104kg

  • VESA Mount

    800 x 400mm

  • Protection Glass

    Optional

  • Media Player Option Type

    Internal

Operation

  • Operating Temperature

    10°C - 40°C

  • Humidity

    10 - 80%

General Feature

  • Key

    Professional heavy usage

  • Special

    Lamp Error Detection, Anti Retention, Brightness Sensor, Temperature Sensor, Built-In Fan Control, RS232C MDC, Built in Speaker (15W + 15W), Plug and Play (DDC2B, DDC / CI), PIP / PBP, Video Wall (5 x 5), Pivot Display, Button Lock, Digital Daisy Chain, Magicinfo Pro, Windows XP embedded

Power

  • Power Supply

    AC 100 - 240V~ (+/ - 10%), 50/60Hz

  • Power Consumption
    Off Mode

    Less than 5W

    On Mode

    790W (Max) / 750W (Typ)

    Sleep Mode

    Less than 5W

  • Type

    Internal

Accessory

  • Included

    Quick Setup Guide, Warranty Card, Application CD, D-Sub cable, Power Cord, Remote Controller, Batteries, BNC to RCA Jack (3EA)

  • Optional
    Mount

    WMN7070D, VMN7070D

Embedded PC

  • CPU

    Athlon X2 Dual-Core

  • N/B

    AMD

  • S/B

    AMD

  • GPU

    AMD

  • FDM/HDD

    SSD 32GB

  • Memory

    DDR2 1GB

  • Ethernet

    Marvell 88E8055 Gigabit LAN

  • Connectivity
    USB

    4EA

    Output

    D-SUB (RGB OUT)

    Others

    LAN RJ45

Certification

  • EMC

    FCC (USA) FCC Part 15, Subpart B class ACE (Europe) EN55022, EN55024VCCI (Japan) V-3 (CISPR22) KCC (Korea): KN22, KN24BSMI (Taiwan): CNS13438 (CISPR22) C-Tick (Australia): AS / NZS3548 (CISPR22) CCC (China): GB 9254-2008, GB 17625.1-2003

  • Safety

    UL (USA): UL 60950-1CSA (Canada): CSA C22.2 No. 60950-1 TUV (Germany): EN60950-1NEMKO (Norway): EN60950-1 KC (Korea): K60950-1 CCC (China): GB 4943-2001PSB (Singapore): IEC60950-1GOST (Russia): IEC60950-1, EN55022SIQ (Slovenia): IEC60950-1, EN55022PCBC (Poland): IEC60590-1, EN55022NOM (Mexico): NOM-019-SCFI-1993IRAM (Argentina):IEC60950-1SASO (Saudi Arabia): IEC60950-1
