22" NC220 Thin Client Monitor


22 NC220 Thin Client Monitor

Recycling Batteries Responsibly

  • The European Directive on Batteries and Accumulators aims to minimise the impact of batteries on the environment and encourage the recovery of the materials they contain. In the UK, regulations on the recycling of batteries and accumulators (rechargeable batteries) were Introduced in 2009. The Waste Batteries Regulations aim to significantly increase UK collection and recycling of used portable batteries from 3% in 2007 to 25% by 2012, rising to at least 45% in 2016.

  • The battery symbol on a product or on its packaging indicates that the product must not be disposed of with general household waste. Instead, it is the consumer’s responsibility to dispose of their waste batteries at a designated collection point so that they can be recycled. The separate collection and recycling of batteries at the time of dispo sal will help to conserve natural resources and ensure that they are recycled in a manner that protects human health and the environment. A comprehensive list of battery recycling centres can be obtained from: www.recycle-more.co.uk

  • All Samsung products that are subject to the Batteries Directive are compliant with the UK battery and accumulator Requirements. In accordance with national law, SAMSUNG Electronics (UK) Ltd is a member of an approved batteries producer compliance scheme. This scheme collects, treats and disposes of batteries on Samsung’s behalf.

22" NC220 Thin Client Monitor


Security you can trust

Security you can trust
Because software is installed, and important information is stored on centralized host platforms, the entire system is secured against viruses, information leaks, and internal and external attack.

Low cost, low maintenance

Low cost, low maintenance
Because all software and data is stored on the centralised host platform, time and money spent on managing the system is vastly reduced, enabling the creation of a network that is easy to install and easy to maintain.

Real-time graphics

Real-time graphics
Through hardware decoding a wide variety of content can be supported from video using any CODEC all the way to high performance 3D content when using a PCoIP enabled workstation platform.

Full USB device support

Full USB device support
With 4 USB ports and full USB device support, users can access a wide range of USB peripheral devices directly through the monitor, enhancing connectivity whilst maintaining the security of the system.
LED Panel

LED Panel

Make sure your environmental impact is a positive one. Samsung’s Cloud Display uses innovative LED Back Light Unit (BLU) technology which saves energy—up to 40% compared to conventional CCFL screens. What’s even better is this LED panel is halogen- and mercury-free, so you’ll help conserve our planet’s natural resources and reduce carbon emissions.
All-in-one design

All-in-one design

Samsung's innovative Cloud Display integrates a thin client into the LED screen for greater efficiency. Its contemporary and innovative design ensures that keeping your work environment clean and tidy is simple. The benefit of having a separate thin client box is that professionals can use their desk space in a much more efficient manner. Other great features include Power-over-Ethernet option, which reduces a power cable by providing power through a LAN cable, and the embedded speaker system. These innovative features come together perfectly for an all-in-one design that enhances desktop productivity.
Monitor remote management S / W

Monitor remote management S / W

Samsung’s Cloud Monitor delivers amazing levels of convenience by using the remote management software of MagicRMS Pro. It delivers a more centralised operation and saves administrators the time and hassle associated with physically having to visit each device for routine checks. Other benefits include real-time device status monitoring, an efficient and accurate inventory process and finally remote upgrading of firmware to all devices. With so many standout benefits for day-to-day operations, the MagicRMS software really is essential to any efficient office environment.
VMware Certified PCoIP Cloud Monitor

VMware Certified PCoIP Cloud Monitor

Innovative PCoIP technology allows consolidation of IT resources into a data centre, and provides high-performance computing via the IP network without reduction in performance or information. Providing a completely virtualized set of hardware to the client operating system. It lets you rus virtual multiple machines seamlessly. At the desktop, the intgrated PCoIP portal decompresses and distributes video, audio and data contents while preserving high performance and real-time graphics.
Access to superior graphics

Access to superior graphics

Superior graphics are enabled by the PCoIP protocol, giving users access to full performance graphics from VMware View enabled virtual machines. Full 3D performance is also available when using PCoIP enabled workstation platforms or PCoIP Host cards in standard PC’s in conjunction with a GPU.

tech specs

Dimension of LF22NEBHBN/ZA


  • H-Scanning Frequency

    31 ~ 80kHz

  • V-Scanning Frequency

    56 ~ 75Hz


  • Diagonal Size


  • Type

    a-Si TFT active matrix

  • Resolution

    1680 x 1050

  • Pixel Pitch(mm)

    0.282 (H) x 0.282 (V) mm

  • Active Display Area

    473.76 (H) x 296.1 (V) mm

  • Brightness


  • Contrast Ratio (Dynamic)


  • Viewing Angle (Horizontal/Vertical)

    170° / 160° deg (CR ≥ 10)
    178° / 178° deg (CR ≥ 5)

  • Response Time (G-to-G)


  • Display Colour

    16.7 million

  • Contrast Ratio




  • Input

    RGB-in (Analog-in)





  • Output



    DVI-out (for Dual, Digital-out)



    Power Out


  • External Control


  • External Sensor


Mechanical Specification

  • Dimension
    Set Dimension (WxHxD)

    508 x 388.4 x 197mm (with Stand)
    508 x 388.4 x 50.5mm (w/o Stand)

    Package Dimension (WxHxD)

    585 x 422 x 167mm

  • Weight
    Set Weight


    Package Weight


  • VESA Mount

    100 x 100

  • Stand Type

    HAS Stand (Function: HAS 130mm, Tilt, Swivel)


  • Operating Temperature

    10ºC ~ 40ºC

  • Humidity

    10% ~ 80%

General Feature

  • Key

    LED backlight, No local O / S


  • Power Supply

    100 - 240V (50 / 60Hz)

  • Power Consumption
    Off Mode

    0W (Mechanical switch off)

    On Mode

    35W (idle), 51W (max.)

    Sleep Mode

    No sleep mode for NC products

  • Type

    External Adaptor


  • Included

    - User Manual
    - Power Cord
    - Adaptor
    - Quick Setup Guide
    - Warranty Card

Embedded PC

  • CPU

    Teradici Tera1100

  • Ethernet

    10 / 100 / 1,000

  • Connectivity

    USB 1.1 x 4EA


    (1) Video Out (DVI, for dual)
    (2) LAN 2EA (RJ 45, Giga) (function: LAN hub)
    (3) Audio (HeadPhone)
    (4) Serial Port
    (5) Optional Built-in Speaker (1.5W x 2)


  • EMC


  • Environment


  • Safety
