20ppm Multi-function Printer CLX-6220FX

CLX-6220FX

Samsung’s focus on high specification and quality colour prints has shaped the development of this multifunctional printer range. When your business demands high performance levels of printing, scanning and copying the Samsung CLX-6220FX / 6250FX range is an ideal option. The Samsung CLX-6220FX / 6250FX range offers consistently outstanding colour prints, copies, scanning as well as minimising operational costs. 5 5 1 reviews

Recycling Batteries Responsibly

  • The European Directive on Batteries and Accumulators aims to minimise the impact of batteries on the environment and encourage the recovery of the materials they contain. In the UK, regulations on the recycling of batteries and accumulators (rechargeable batteries) were Introduced in 2009. The Waste Batteries Regulations aim to significantly increase UK collection and recycling of used portable batteries from 3% in 2007 to 25% by 2012, rising to at least 45% in 2016.

  • The battery symbol on a product or on its packaging indicates that the product must not be disposed of with general household waste. Instead, it is the consumer’s responsibility to dispose of their waste batteries at a designated collection point so that they can be recycled. The separate collection and recycling of batteries at the time of dispo sal will help to conserve natural resources and ensure that they are recycled in a manner that protects human health and the environment. A comprehensive list of battery recycling centres can be obtained from: www.recycle-more.co.uk

  • All Samsung products that are subject to the Batteries Directive are compliant with the UK battery and accumulator Requirements. In accordance with national law, SAMSUNG Electronics (UK) Ltd is a member of an approved batteries producer compliance scheme. This scheme collects, treats and disposes of batteries on Samsung’s behalf.

20ppm Multi-function Printer CLX-6220FX

Features

  • Streamline your office, maximise productivity

Samsung Easy Colour Manager

Samsung Easy Colour Manager
Easy Colour Manager allows users to easily adjust colour balance, brightness, contrast and saturation of any image that you view on your monitor. It can be especially useful if you have specific colour preferences, or if your company has its own brand requirements.

duplex printing

duplex printing
With the Samsung CLX-6220FX / 6250FX range duplex printing has been made easier and more convenient with the removal of the unnecessary need for paper reinsertion. The duplex automatic document feeder saves time and money by loading several sheets at a time to be able to print double-sided documents automatically, including faxes.

Samsung’s Real-time Calibration technology

Samsung’s Real-time Calibration technology
Samsung’s Real-time Calibration technology ensures documents are printed to a consistently high colour quality. However, when dealing with important documents that require special attention, users can choose to manually define the colour quality that will appear on their documents. The enhanced CTD (Colour Toner Density) sensor ensures colour output is always clear, sharp and professional.

Power Save mode

Power Save mode
Reduces the cost of printing and lowers the temperature of the machine, creating a more durable environment for the printer components. Less wear and tear means extended quality and fewer replacement parts needed.

high resolution

high resolution
Communication is key in any business. Colour print quality can make your company stand out. The Samsung CLX-6220FX / 6250FX range excels in its printing capability by featuring a resolution level of 9600 x 600 dpi and high glossiness level, providing you with consistent professional documents.

Blue Compass Navigation

Blue Compass Navigation
Samsung’s unique Blue Compass Navigation with 4 Line LCD screen is easy to learn and even easier to use, so you can be more productive, more quickly. The navigation array gives you instant access to all the different print functions and controls. Simple, intuitive menus and buttons add to the savings in training and troubleshooting time. 4 line LCD screen make operations quick and easy, and printer control panels have everything covered, including job status, toner level, paper jam, paper empty and cover open alerts.

toner management

toner management
With the Toner Save mode you can monitor and effectively limit your toner usage for a cost effective business solution. Using less toner on each page can extend your cartridge life, significantly reducing your cost per page and helping to meet environmental standards.

direct USB interface

direct USB interface
The Samsung CLX-6220FX / 6250FX range utilises the latest technology to ensure total convenience. With a USB port located on the front of the printer you can easily access and print the files stored on your USB drive. With a wide range of files supported from PDF, BMP, TIFF and JPEG you can save time by printing straight from the USB drive.
high speed

high speed

Users benefit from a high speed printer, copier and scanner that offers high resolution document printing. The Samsung CLX-6220FX / 6250FX range has a 20 - 24 ppm print speed as well as a first page out time of as fast as 17 seconds*. * 17 s refers to CLX-6250FX only.
enhanced specification

enhanced specification

With a 360 / 700 MHz CPU* and a generous 256 MB RAM, the Samsung CLX-6220FX / 6250FX range makes it easy to process, store and handle jobs. The added features and processing power mean it’s suitable for the most demanding office environment. * 700 MHz CPU refers to CLX-6250FX only.
smooth network integration

smooth network integration

Conveniently network ready the Samsung CLX-6220FX / 6250FX range is easy to integrate into your IT infrastructure. Future-proof capabilities for the next generation of Internet protocol (IPv6).

energy efficient

Samsung’s Instant Fusing technology utilises low energy lamps for heating the internal print roller rather than the traditional high energy heating elements. This allows for a more energy efficient and faster printer.

tech specs

Dimension of CLX-6220FX/XAA

Overview

  • Function

    Colour Print, Copy, Fax, Scan

Print

  • Speed(Mono)

    up to 20 ppm in A4 (21 ppm in letter)

  • Speed(Colour)

    up to 20 ppm in A4 (21 ppm in letter)

  • First Print Out Time (Mono)

    as fast as 24 seconds

  • First Print Out Time (Colour)

    as fast as 24 seconds

  • Resolution

    up to 9600 x 600 dpi effective output

  • Emulation

    PostScipt3, PCL5c, PCL6, SPL-C (Samsung Printer Language Colour)

  • Duplex

    bulit-in

SHOW MORE SPECSExpand

Copy

  • Speed(Mono)

    up to 20 cpm in A4 (21 cpm in letter)

  • Speed(Colour)

    up to 20 cpm in A4 (21 cpm in letter)

  • Resolution

    best : 9600 x 600 dpi effective output
    normal : 1200 x 600 dpi
    draft : 600 x 600 dpi

  • First Copy Out Time (Mono)

    as fast as 27 seconds

  • First Copy Out Time (Colour)

    as fast as 27 seconds

  • Zoom Rate

    25 ~ 400% (platen), 25 ~ 100% (ADF)

  • Multi Copy

    1 ~ 99

  • Duplex Copy

    built-in

  • Copy Features

    ID Copy, Clone Copy, N-up Copy, Poster Copy

Scan

  • Compatibility

    TWAIN standard, WIA standard (Windows XP only)

  • Method

    colour flatbed scanner or DADF

  • Resolution (Optical)

    up to 600 x 600 dpi

  • Resolution (Enhanced)

    up to 4800 x 4800 dpi

  • Scan to

    USB / SMB / FTP / network / e-mail

FAX

  • Compatibility

    ITU-T G3

  • Modem speed

    33.6 Kbps

  • Resolution

    up to 300 x 300 dpi (B / W), 200 x 200 dpi (colour)

  • Memory

    8 MB

  • Auto Dial

    Yes

  • Fax Feature

    Colour Fax, PC-Fax (mono send only, included in SmarThru Office)

Paper Handling

  • Input Capacity and Types

    250-sheet cassette, 100-sheet multi-purpose tray

  • Output Capacity and Types

    up to 170 - sheet @ 80 g/m² face down

  • Media Size

    76 x 127 mm (3" x 5") ~ 216 x 356 mm (8.5" x 14")

  • Media Type

    Envelopes, Labels, Card Stock, Bond, Archive

  • Capacity

    50 - sheet

  • ADF Document Size

    width : 142 ~ 216 mm (5.6" ~ 8.5")
    length : 148 ~ 356 mm (5.8" ~ 14")

General Feature

  • LCD

    16 x 4 line LCD (white back light)

  • Memory/Storage

    256 MB (max. 512 MB)

  • OS Compatibility

    Windows 2000 / XP / 2003 / Vista (include 64 bit) / 7 Various Linux OS, Mac OS X 10.3 ~ 10.5

  • Interface

    hi-speed USB 2.0, Ethernet 10 / 100 base-TXUSB host 2.0 (scan to USB, USB print)

  • Noise Level

    less than 53 dBA (printing)
    less than 54 dBA (copying)
    less than 32 dBA (standby)

  • Duty Cycle, Monthly

    up to 65000 pages

  • Dimension (WxDxH)

    468 x 498 x 651 mm

  • Weight

    36 kg

Consumables

  • Black Toner Cartridge

    average continuous black cartridge yield
    high yield : 5000 standard pages
    standard yield : 2500 standard pages (ships with 2500 pages standard toner cartridge)

  • Yellow/Magenta/CyanToner Cartridge

    average continuous yellow / magenta / cyan cartridge yield
    high yield : 4000 standard pages
    standard yield : 2000 standard pages (ships with 2000 pages standard toner cartridge)

  • Transfer Belt

    approx. 50000 pages (CLT-T508)

Option

  • Options

    128 MB memory : CLP-MEM201
    256 MB memory : CLP-MEM202
    second cassette feeder : CLX-S6250A
