700TSN-2 Equipped with 70" large display, the Samsung 700TSn-2 LFD combines brilliant image quality and interactive controls to deliver a totally professional service. Its fast screen response time gives the smoothest and most effective fingertip control. And with a sheet of protective glass over the display area, your touch-screen presentations have never been in safer hands.

Recycling Batteries Responsibly

  • The European Directive on Batteries and Accumulators aims to minimise the impact of batteries on the environment and encourage the recovery of the materials they contain. In the UK, regulations on the recycling of batteries and accumulators (rechargeable batteries) were Introduced in 2009. The Waste Batteries Regulations aim to significantly increase UK collection and recycling of used portable batteries from 3% in 2007 to 25% by 2012, rising to at least 45% in 2016.

  • The battery symbol on a product or on its packaging indicates that the product must not be disposed of with general household waste. Instead, it is the consumer’s responsibility to dispose of their waste batteries at a designated collection point so that they can be recycled. The separate collection and recycling of batteries at the time of dispo sal will help to conserve natural resources and ensure that they are recycled in a manner that protects human health and the environment. A comprehensive list of battery recycling centers can be obtained from: www.recycle-more.co.uk

  • All Samsung products that are subject to the Batteries Directive are compliant with the UK battery and accumulator Requirements. In accordance with national law, SAMSUNG Electronics (UK) Ltd is a member of an approved batteries producer compliance scheme. This scheme collects, treats and disposes of batteries on Samsung’s behalf.

700TSN-2

Features

  • 70" large display delivers brilliant images in true-to-live color and remarkable interactive controls.
  • With fast screen response time, you can enjoy the smoothest and most effective fingertip control.

A smart sensor that automatically saves energy.

A smart sensor that automatically saves energy.
Stop worrying about the lighting conditions affecting your display. This Samsung LFD adjusts its brightness levels as ambient light changes so your images are always crystal-clear. And while it compensates for low-light and high-light environments, you’ll save energy and stay eco-friendly.

Reliable, durable and dust-resistant.

Reliable, durable and dust-resistant.
Introducing a monitor that was built to stand the test of time—and dust. This Samsung LFD is durable and dust-resistant. Corner-sealing design, double-layer structure, and screw and user hole sealing add to its ruggedness. Make sure dirt and dust don’t stand in the way of getting your message out.

Brighter lights, better picture.

Brighter lights, better picture.
With an intensely illuminated DID panel your message is always in the spotlight. Its high brightness and contrast level make the screen clear and readable in public. In fact, on average it’s 1.5 times as bright as TV screens. Plus with a low operating temperature this Samsung LFD will be completely reliable for years to come.

Save money, save space with built-in speakers.

Save money, save space with built-in speakers.
Maximize your impact with a great picture and crisp audio. Your message will be heard loud and clear with built-in speakers. You’ll save money when you eliminate the cost of purchasing separate speakers, and you’ll save valuable space as well.

A cool way to ensure longevity.

A cool way to ensure longevity.
Enjoy continuous, reliable operation thanks to a built-in fan control. Housed inside of the LFD, the fan guarantees you can count on it for years to come without worrying about it overheating. You can even control the fan with an easy-to-use on screen display.

Choose the right view, landscape or portrait.

Choose the right view, landscape or portrait.
This Samsung LFD gives you the flexibility to display your image vertically or horizontally—whatever the situation calls for. With a pivot function that rotates the screen 90˚degrees and the freedom to display presentations in portrait mode or advertisements in landscape mode, this makes for one versatile monitor.

A screen that won’t shatter your digital dreams.

A screen that won’t shatter your digital dreams.
When a monitor is displayed in public areas, things can happen. That’s why our LFD offers a specially-designed, optional protection glass. Scratch resistant and shatter-proof, it shields the panel’s surface from any damage so you can use it for years to come.

Stay in the loop with DVI-out.

Stay in the loop with DVI-out.
Enjoy superior picture quality with a DVI-out interface that lets you share content between multiple LFDs thanks to an easier-to-connect video matrix. LFDs used to have to be connected to the PC individually, but digital loop out allows you to connect them without connecting to a PC. Better yet, the digital loop out produces a single image without any loss of quality, and there’s no need for a separate video signal distributor. It’s easy to install and the most cost-effective way to connect multiple displays.

Twice the information, double the impact.

Twice the information, double the impact.
Whether your presentation requires a picture-in-picture configuration or a picture-by-picture arrangement, this Samsung LFD makes it possible. When one image just isn’t enough, two video signals can be viewed simultaneously for maximum impact.

An innovative solution with easy access.

An innovative solution with easy access.
Samsung’s network management software features two types: a Wan/Lan-based for local access and a web-based software accessible anywhere. MagicInfo™ lets you access your server and LFDs everywhere in the world. This optimized Samsung software solution lets you manage multiple Samsung LFDs remotely. Best yet, uploading, creating, monitoring and controlling content is more convenient and less time-consuming.

No separate PCs. No jumbled wires.

No separate PCs. No jumbled wires.
Control multiple monitors without having to install and run wires to a separate PC. This Samsung LFD features a powerful built-in PC. Its optional multi-network solution—purchased separately—is easy to configure through a LAN, easy to manage through server-side software, and cost-effective to run. And with optimized CPU, RAM and storage, you’ll have everything you need to get your message across effectively.

On-screen interactivity built-right-in.

On-screen interactivity built-right-in.
This Samsung LFD is ready to interact with your customers. It features a convenient, embedded touch module so they can get started immediately. With advanced touch sensors, it reacts quickly their every touch—in corners or anywhere else on the screen. Customers enjoy more interaction with access to the entire screen.

A great picture that’s glare-free.

A great picture that’s glare-free.
Whether you have a story to tell or a product to sell, it’s important that your image is crystal clear. This Samsung LFD delivers just that—even if your display is located in a brightly-lit environment. It eliminates any reflections that can disrupt your ad’s readability, keeping images smooth and visible.

tech specs

Dimension of LH70TCSMBG/ZA

Display

  • H-Scanning Frequency

    30kHz ~ 81kHz

  • Maximum Pixel Frequency

    165MHz

  • V-Scanning Frequency

    56Hz ~ 85Hz

Panel

  • Diagonal Size

    70"

  • Technology

    S-PVA (DID)

  • Resolution

    WXGA 1920 x 1080 (16:9)

  • Pixel Pitch(mm)

    0.807 (H) x 0.807 (V)

  • Active Display Area

    1549.44 (H) x 871.56 (V)

  • Brightness

    600cd/m2

  • Contrast Ratio (Dynamic)

    2500:1

  • Viewing Angle(Horizontal/Vertical)

    178/178

  • Response Time (G-to-G)

    8ms

  • Display Color

    8 bit - 16.7M

  • Color Gamut

    72%

  • Contrast Ratio

    2000:1

  • Light Source Type

    CCFL

SHOW MORE SPECSExpand

Connectivity

  • Input
    RGB

    Analog D-SUB, DVI-D

    Video

    CVBS, Component, BNC, HDMI

    Audio

    RCA (L/R) , Stereo mini Jack

  • Output
    RGB

    DVI-D (Loop-out)

    Audio

    Stereo mini Jack

  • External Control

    RS232C (in/out)

  • Network

    Embedded

Specification

  • Dimension (WxHxD)
    Set Dimension (WxHxD) (mm)

    1688 x 989 x 154 mm

    Package Dimension (WxHxD) (mm)

    1825 x 1353 x 610mm

  • Weight (g)
    Set Weight (kg)

    122kg

    Package Weight (kg)

    148kg

  • VESA Mount (mm)

    800 x 400mm

  • Protection Glass

    Yes

  • Media Player Option Type

    Internal

Operation Time

  • Operating Temperature (℃)

    10℃ ~ 40℃

  • Humidity (%)

    10 ~ 80%

General Feature

  • Touch Screen Module

    Embedded

  • Key

    All-in-one Touchscreen

  • Special

    Embedded Touch (IR) ,Lamp Error Detection, Anti Retention, Brightness Sensor, Temperature Sensor, Built-In Fan Control, RS232C MDC, Built in Speaker (15W + 15W), Plug and Play (DDC2B, DDC/CI), PIP/PBP, Video Wall(5x5), Pivot Display, Button Lock, Digital Daisy Chain, Magicinfo Pro, Windows XP embedded

Power

  • Power Supply

    AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

  • Power Consumption
    Off Mode

    less than 5W

    On Mode

    790W (Max) / 750W (Typ)

    Sleep Mode

    less than 5W

  • Technology

    Internal

Accessory

  • Included

    Quick Setup Guide, Warranty Card,Application CD,D-Sub cable, Power Cord,Remote Controller, Batteries,BNC to RCA Jack x 3

  • Optional
    Mount

    WMN7070D, VMN7070D

Embedded PC

  • CPU

    Athlon X2 Dual-Core 4450e (2.3GHz)

  • N/B

    AMD RS780

  • S/B

    AMD SB700

  • GPU

    AMD RS780 (IGP)

  • FDM/HDD

    SSD 32GB

  • Memory

    DDR2 1GB

  • Ethernet (LAN)

    Marvell 88E8055 Gigabit LAN

  • Connectivity
    USB

    4

    Output

    D-SUB (RGB OUT)

    Others

    LAN RJ45

Certification

  • EMC

    FCC (USA) FCC Part 15, Subpart B class ACE (Europe) EN55022, EN55024VCCI (Japan) V-3 (CISPR22)KCC (Korea) : KN22, KN24BSMI (Taiwan) : CNS13438 (CISPR22)C-Tick (Australia) : AS/NZS3548 (CISPR22) CCC(China) : GB 9254-2008, GB 17625.1-2003

  • Safety

    UL (USA) : UL 60950-1CSA (Canada) : CSA C22.2 No. 60950-1 TUV (Germany) : EN60950-1NEMKO (Norway) : EN60950-1 KC (Korea) : K60950-1 CCC (China) : GB 4943-2001PSB (Singapore) : IEC60950-1GOST (Russia) : IEC60950-1, EN55022SIQ (Slovenia) : IEC60950-1, EN55022PCBC (Poland) : IEC60590-1, EN55022NOM (Mexico) : NOM-019-SCFI-1993IRAM (Argentina) :IEC60950-1SASO (Saudi Arabia) : IEC60950-1

Support

User Manual

6.2 MB, pdf, ENGLISH

2012.01.20

Other Manuals (4)

Driver (1)

  • Device(Install)

    Win 98/ME/2K/XP/X64/Vista/Vista 64/Win7/Win7 64, 0.05 MB, exe, MULTI LANGUAGE

    Version : 1.0

    2010.01.06 tooltipbox

    Close tooltip pop-up
    1. Title
    Monitor Driver
    2. Applicable Model
    SyncMaster 700TSN-2
    3. Carrier or Corporate Customer
    Open Market
    4. Description
    If you have trouble for setting up the Monitor under Windows 98/Me/2000/XP/X64/Vista/Vista64, this program will help you to install Windows Monitor Driver. You can install the most suitable Windows driver for your monitor.

    System Requirements : Windows 98/Me/2000/XP/X64/Vista/Vista64 /Windows7(32bit/64bit)
