- Best Picture Quality
- Best Picture Quality
- SIM (Slide in Module) - External attachable option module
- Touch Screen with P/glass, Display port
- RS232/RJ45 MDC, 2 HDMIs, Smart Scheduling
Enhanced connectivity without extra costs.
Easy control goes the distance.
Set a schedule that's always on time.
A video wall that lives up to your standards
Save money, save space with built-in speakers.
A cool way to ensure longevity.
Choose the right view, landscape or portrait.
A screen that won't shatter your digital dreams.
Twice the information, double the impact.
On-screen interactivity built-right-in.
A great picture that's glare-free.
A slide-in design with easy accessibility.
Diagonal Size101.60cm (40)
TypeS-PVA ( B-DID)
Resolution1920 x 1080 (16:9)
Pixel Pitch(mm)0.46125 (H) x 0.46125 (V)
Active Display Area885.60 (H) x 498.15 (V)
Response Time (G-to-G)8ms
Display Color8 bit - 16.7M
H-Scanning Frequency30kHz ~ 81kHz
V-Scanning Frequency56Hz ~ 85Hz
Maximum Pixel Frequency148.5MHz
RGBAnalog D-SUB, DVI-D, Display Port
VideoCVBS, HDMI1, HDMI2, Component (D-sub 15pin)
AudioRCA (L/R), Stereo mini Jack
Power Out5V (for SBB)
External ControlRJ45, RS232C (in/out), USB B type (touch screen)
Power SupplyAC 100 - 240 V ~ (+/- 10 %), 50/60Hz
On Mode235 watts (max)/193 watts (typ)
Sleep ModeLess than 2 watts
Off ModeLess than 1 watts
Set Dimension (WxHxD)973.2 x 584.4 x 128.1
Package Dimension (WxHxD)1,085 x 703 x 310
VESA Mount600 x 400mm
Stand TypeFoot Stand (optional)
Media Player Option TypeSIM (Slide in Module)
Operating Temperature10°C ~ 40°C
Humidity10 ~ 80%
SpecialEmbedded Touch (IR), Lamp Error Detection, Brightness Sensor, Anti Retention, Temperature Sensor, RS232C/RJ45 MDC, Built in Speaker (10 watts + 10 watts), Plug and Play (DDC2B), PIP/PBP, Video Wall (10 x 10), Pivot Display, Button Lock, Smart Scheduling, Smart F/W update
SafetyUL (USA): UL 60950-1 CSA (Canada): CSA C22.2 No. 60950-1 TUV (Germany): EN60950-1 NEMKO (Norway): EN60950-1 KC (Korea): K60950-1 CCC (China): GB 4943-2001 PSB (Singapore): IEC60950-1 GOST (Russia): IEC60950-1, EN55022 SIQ (Slovenia): IEC60950-1, EN55022 PCBC (Poland): IEC60590-1, EN55022 NOM (Mexico): NOM-019-SCFI-1993 IRAM (Argentina): IEC60950-1 SASO (Saudi Arabia): IEC60950-1
EMCFCC (USA) FCC Part 15, Subpart B class A CE (Europe) EN55022, EN55024 VCCI (Japan) V-3 (CISPR22) KCC (Korea): KN22, KN24 BSMI (Taiwan): CNS13438 (CISPR22) C-Tick (Australia): AS/NZS3548 (CISPR22) CCC (China): GB 9254-2008, GB 17625.1-2003
EnvironmentENERGY STAR 5.0 (USA)
IncludedQuick Setup Guide, Warranty Card,Application CD, D-Sub cable, Power Cord, Remote Controller, Batteries
SpecialtyCML500D (ceiling mount), STN-520WE (welcome Board)
