AS12EUQN

AS12EUQN

Air conditionet dazzles with its high glossy panel, making your home sparkle sparkle with luxury. You can enjoy clean, refreshing air with its strong power and purifying functions.

Recycling Batteries Responsibly

  • The European Directive on Batteries and Accumulators aims to minimise the impact of batteries on the environment and encourage the recovery of the materials they contain. In the UK, regulations on the recycling of batteries and accumulators (rechargeable batteries) were Introduced in 2009. The Waste Batteries Regulations aim to significantly increase UK collection and recycling of used portable batteries from 3% in 2007 to 25% by 2012, rising to at least 45% in 2016.

  • The battery symbol on a product or on its packaging indicates that the product must not be disposed of with general household waste. Instead, it is the consumer’s responsibility to dispose of their waste batteries at a designated collection point so that they can be recycled. The separate collection and recycling of batteries at the time of dispo sal will help to conserve natural resources and ensure that they are recycled in a manner that protects human health and the environment. A comprehensive list of battery recycling centres can be obtained from: www.recycle-more.co.uk

  • All Samsung products that are subject to the Batteries Directive are compliant with the UK battery and accumulator Requirements. In accordance with national law, SAMSUNG Electronics (UK) Ltd is a member of an approved batteries producer compliance scheme. This scheme collects, treats and disposes of batteries on Samsung’s behalf.

AS12EUQN

Features

  • Smart Saver - Up to 31% energy saving
  • Zero Standby Power - Up to 90% energy saving
  • Virus Doctor - Eliminates up to 99.99% influenza type A virus
  • Full HD Filter - Filtrates 80% of dust

LED puts temperature on display.

LED puts temperature on display.
From young to old, checking the temperature is easy for everyone with Samsung's family-friendly display window. Its easy-to-read, oversized numbers beam out in bright, white luminescence for instant temperature recognition. And the simple, eye-catching icons make it a breeze to use.

A cool way to keep your air clean.

A cool way to keep your air clean.
You might not know it, but an air conditioner can produce mold and spread germs. That's because the difference between internal and external air temperatures causes moisture to form inside the unit—and moisture equals bacteria. Our solution? Samsung air conditioners feature auto cleaning, which automatically runs the fan even after you turn it off, keeping everything dry and odor-free while preventing germs from spreading.

Built to blast. And built to last.

Built to blast. And built to last.
Unlike typical air conditioners, this Samsung AC was built to blow cool air without blowing out. Air conditioners generally aren't designed to endure wide fluctuations in voltage. But the Samsung AC runs stably under a persistently high and low voltage of up to 25% deviation without putting excessive strain on the compressor. This is great news during the middle of summer and for remote regions with unstable voltage supplies.

Easy to use. Easy to master.

Easy to use. Easy to master.
Samsung's ergonomic, innovative remote control was designed for everyone, whether you're in the first grade or celebrating your 81st birthday. With bigger numbers, soft-touch buttons, an easy-view display and a comfy grip, you're always in control. And its circular navigation keypad truly brings power to the people.

Total stability for a maximum comfort.

Total stability for a maximum comfort.
Stay perfectly, perpetually cool with Samsung's built-in Stabiliser-Free. It automatically stabilises the voltage to prevent sudden power failures ensuring that your comfort isn't compromised no matter the circumstance. And its worry-alleviating operation is enhanced by its sleek, sophisticated looks and space-saving, wall-mounted convenience.

Bright light. Deep breath.

Bright light. Deep breath.
Don't hold your breath till you turn blue. Samsung's Blue LED Lamp lets you breathe easy knowing that your AC is pumping out clean, healthy air. As soon as MPI function's switched on, your Samsung air conditioner begins the air purification process so you're always taking breathing the freshest air. And the Blue LED indicator gives you total peace of mind as it shines its approval of the pristine air quality of your home.
Keep it on and keep it cool.

Keep it on and keep it cool.

With Smart Saver, you no longer have to go through the annoyance of turning your air conditioner off as soon as you feel the room is sufficiently cooled, and then turning it back on when the room begins to warm back up. Smart Saver automatically runs the AC in the least amount of time necessary to keep the room comfortable, saving electricity up to 31% so your bill stays low and you stay cool.

Slim design. Powerful output.

Slim design. Powerful output.
Design should never be an afterthought. Samsung's new slim, sleek ACs are 12% smaller and 20% lighter but perform as powerfully as their larger counterparts. An exclusive slim design not only ensures that they are lightweight, easy-to-install and space-saving, but makes them a sophisticated aesthetic presence in your home as well.
Comfort Care helps you enjoy your environment.

Comfort Care helps you enjoy your environment.

You might have the AC set at the perfect temperature, but that doesn't mean you'll always be perfectly comfortable. In fact, temperature is only one part of the equation in achieving total comfort. Even as the AC holds steady at your precise, ideal temperature, varying levels of humidity in the air can compromise your comfort. But Samsung's Comfort Care technology measures the humidity and temperature of the room and adjusts both automatically until the comfort index is reached.
Turns your home into an Intensely Purified Zone.

Turns your home into an Intensely Purified Zone.

Talk about a breath of fresh air. Samsung's Virus Doctor system dramatically improves indoor air quality so your every breath is a pure, healthy one. It eliminates invisible, health-threatening biological contaminants such as viruses, bacteria and allergy-causing agents, protecting you from disease and everyday illnesses. Purifying over 19.16m3 of space, the Virus Doctor system not only blows a lot of fresh air into a home, it blows away the competition.
A silver coated solution.

A silver coated solution.

A good air conditioner shouldn't just cool you down; it should also circulate clean, fresh air. Samsung Air Conditioners feature an Anti-Virus filter and an evaporator with a silver finish. 1.6 times stronger than your typical pre-filter, this super fine silver filter, made with thin filaments 1/3 the width of a human hair, is designed to eliminate microscopic dust particles, fungi and unpleasant odors. So now you can cool off and relax with clean and cool air.

tech specs

Dimension of AS12EUQNXEA

Performance

  • Capacity (Cooling, Btu/hr)
    Btu/hr
    12,000
  • Capacity (Cooling, Cal/hr)
    Cal/hr
    3,024
  • Capacity (Cooling, kW)
    Kw
    3.5
  • Energy Efficiency
    EER (Cooling, Btu/W)
    10.7
    EER (Cooling, W/W)
    3.14
    COP (Heating, W/W)
    N/A
  • Moisture Removal (l/hr)
    1.0
  • Air Circulation (Max, m3/min)
    m3/min
    8.0
  • Noise Level
    Indoor High/Low
    36/26
    Outdoor High
    48

Electrical Data

  • Power Source
    Φ/V/Hz
    220 - 240 / 50 / 1
  • Energy Efficiency
    Power Consumption (Cooling)
    800
    Power Consumption (Heating)
    N/A
    Operating Current (Cooling)
    4
    Operating Current (Heating)
    N/A

SHOW MORE SPECSExpand

Physical Specifications

  • Dimension
    Net Dimension (WxHxD, Indoor)
    820*285*190
    Net Dimension (WxHxD, Outdoor)
    660*475*242
  • Weight
    Net Weight (Outdoor)
    26.0
    Shipping Weight (Indoor)
    10
    Shipping Weight (Outdoor)
    30.0
    Net Weight (Indoor)
    8
  • Loading Quantity
    20/40/40HC with Pipe
    104/224/248
    20/40/40HC without Pipe
    120/248/280

Technical Information

  • Refrigerant Type
    R22
  • SVC Valve
    Liquid (ODxL)
    Φ6.35mm
    Gas (ODxL)
    Φ9.52mm
  • Piping Length
    Piping Length (Max)
    15
  • Piping Height
    Piping Height (Max)
    7

General Features

  • Air Purification
    S-Plasma ion
    Yes
    Auto Roof Shutter
    No
    Full HD Filter
    80
    DNA Filter
    No
    Deodorizing Filter
    Yes
    Catechin Filter
    Yes
    Allergy Care
    No
    Anti-bacteria Coating
    Yes
    Auto Clean (Self Cleaning)
    Yes
  • Air Flow
    Wide Twin Blade
    No
    Optimal Single Blade
    Yes
    Air Flow Control Step (Cool/Fan)
    41002
    Air Direction Control (Up/Down)
    Auto
    Air Direction Control (Left/Right)
    Manual
    Natural Breeze
    Yes
  • Operating Mode
    dlight Cool
    No
    good sleep
    Yes
    Smart Saver
    Yes
    Turbo Mode
    Yes
    Dehumidification
    Yes
    Auto Mode
    Yes
    Fan Mode
    Yes
    Quiet
    No
  • Convenience
    Filter Cleaning Indicator
    No
    Indoor Temp. Display
    Yes
    Remote controller
    Yes
    Display On/Off
    Yes
    Beep On/Off
    Yes
    Real-time Timer
    No
    24-Hour Timer
    Yes
    Auto Restart
    Yes
    Auto Changeover
    No
  • Outdoor Unit
    Compressor Type
    ROTARY
    Anti-corrosion Fin
    Yes
    Multi-channel Condensor
    No
  • Low Ambient
    Cooling
    15 - 43
    Heating
    No
