HT-C330

HT-C330

HT-C330 Premium picture quality and spectacular surrond sound are two of the trademarks of Samsung DVD Home Cinema Systems. Combining their unique range of AV enhancement technologies with future - forwarded connectivity, they provide an incredible, immersive multimedia experience.

Recycling Batteries Responsibly

  • The European Directive on Batteries and Accumulators aims to minimise the impact of batteries on the environment and encourage the recovery of the materials they contain. In the UK, regulations on the recycling of batteries and accumulators (rechargeable batteries) were Introduced in 2009. The Waste Batteries Regulations aim to significantly increase UK collection and recycling of used portable batteries from 3% in 2007 to 25% by 2012, rising to at least 45% in 2016.

  • The battery symbol on a product or on its packaging indicates that the product must not be disposed of with general household waste. Instead, it is the consumer’s responsibility to dispose of their waste batteries at a designated collection point so that they can be recycled. The separate collection and recycling of batteries at the time of dispo sal will help to conserve natural resources and ensure that they are recycled in a manner that protects human health and the environment. A comprehensive list of battery recycling centres can be obtained from: www.recycle-more.co.uk

  • All Samsung products that are subject to the Batteries Directive are compliant with the UK battery and accumulator Requirements. In accordance with national law, SAMSUNG Electronics (UK) Ltd is a member of an approved batteries producer compliance scheme. This scheme collects, treats and disposes of batteries on Samsung’s behalf.

HT-C330

Features

  • Total RMS 330W
  • Power Bass
  • ConnectShare™ Movie
  • CD Ripping

USB Host

USB Host
The USB Instant Play feature allows you to connect digital devices such as cameras, mp3 players, and external HDDs and enjoy instant playback of your favourite files. And, the innovative CD Ripping feature enables CDs to be inserted and converted to mp3 format so that they can be stored and enjoyed wherever, whenever.

5.1 Audio Out

5.1 Audio Out
Samsung DVD players support 5.1 channel surround sound output, bringing audio to life with superior surround sound. With a range of advanced audio technologies that combine to create an immersive audio environment that is powerful, precise, and pure.

Power Bass gives your system a big boost.

Power Bass gives your system a big boost.
Your Samsung DVD Home Theatre System is designed to deliver a bigger, better bass sound. It doesn’t require any additional speakers; you can actually feel the bass sound grow more and more powerful on the same speaker system and with the same watt output.
Dolby Pro Logic II

Dolby Pro Logic II

Audio quality you can’t forget starts with Dolby Pro Logic II. Take your surround sound experience to the next level and hear every sound, every special effect that the director intended. With technology this innovative, you’ll enjoy an immersive, theatre - quality sound.
Divx Playback

Divx Playback

Spend more time watching movies and less time waiting for them to download. With Divx playback you’ll skip the lengthy conversion process. Just pop in DVDs and CDs with Divx movies and start watching them on your TV.
CD Ripping

CD Ripping

Take your favourite tracks with you on your MP3 player. In minutes, you can convert your CDs to MP3s with the CD ripping feature. Extract audio tracks from your CDs simply by inserting your CD and pressing the ripping button.

tech specs

Dimension of HT-C330/XME

General Features

  • Total Power

    330watts

  • # of Channels

    5.1

  • Disc Capacity

    1

Playable Disc Type

  • DVD-Video/DVD-R/DVD-RW

    Yes

  • CD DA/CD-R/CD-RW

    Yes

  • DIVX (including XVID)

    Yes

  • MP3

    Yes

  • WMA, WMV (1/2/3/7)

    Yes

  • JPEG

    Yes

  • Full Karaoke (DVD-OK)

    No

SHOW MORE SPECSExpand

Video Features

  • Video Up-Scale (DVD)

    No

  • BD Wise

    No

Audio Features

  • Smart Volume

    No

  • MP3 Enhancer

    Yes

  • Power Bass

    Yes

  • Virtual Surround

    No

  • # of DSP

    8

  • Auto Sound Calibration (ASC)

    No

  • Dolby Digital

    Yes

  • Dolby Pro Logic II

    Yes

  • DTS

    No

Connectivity

  • Bluetooth

    No

  • Anynet+ (HDMI-CEC)

    No

  • USB Host

    Yes

  • Wireless Speaker Ready

    No

  • Wireless Speaker Module included

    No

  • Made for iPod/iPhone

    No

  • Works with iPhone

    No

  • iPod/iPhone Dock Cradle Included

    No

  • HDMI Out

    No

  • Composite Output

    Yes

  • Component Output

    Yes

  • SCART Out

    No

  • HDMI Input

    0

  • Audio Input

    1

  • Optical Input

    1

  • Coaxial Input

    0

  • Headphone Jack

    0

  • MIC Jack

    2

Tuner

  • FM

    Yes

  • RDS

    No

  • AM

    No

  • XM-Ready

    No

Special Feature

  • Multi-Room

    No

  • Crystal Amplifier

    No

  • Energy Star

    Yes

  • Etc.

    CD Ripping (x3)

Speaker

  • Type (Tallboy/Satellite)

    Satellite

  • Unit Material

    Original

  • Front (# of Unit/Unit Size)

    Full Range

  • Center (# of Unit/Unit Size)

    Full Range

  • Surround (# of Unit/Unit Size)

    Full Range

  • Active (Powered) S/W

    No

Dimension & Weight

  • Set Net Weight

    2.5

  • Set Net Dimension (WxHxD)

    430 x 59 x 276mm

  • Sub Woofer Net Dimension (WxHxD)

    155 x 350 x 285mm

  • Front Speaker Net Dimension (WxHxD)

    84.0 x 104.5 x 68.5mm

  • Center Speaker Net Dimension (WxHxD)

    84.0 x 104.5 x 68.5mm

  • Surround Speaker Net Dimension (WxHxD)

    84.0 x 104.5 x 68.5mm

  • Gross Weight: One Packing

    11.0kg

  • Gross Dimension (WxHxD): One Packing

    531 x 334 x 361mm

Support

User Manual

5.29 MB, pdf, ENGLISH

2010.05.11

Other Manuals (1)

Firmware (1)

  • Upgrade File

    All OS, 1.42 MB, zip, ENGLISH

    Version : HTD-C330WWB-1003.1

    2010.05.11
