MAX-DA54T

MAX-DA54

Enjoy music in multiple formats with the higher-performing MAX-DX55, make listening to nature possible without disrupting it visually.

Recycling Batteries Responsibly

  • The European Directive on Batteries and Accumulators aims to minimise the impact of batteries on the environment and encourage the recovery of the materials they contain. In the UK, regulations on the recycling of batteries and accumulators (rechargeable batteries) were Introduced in 2009. The Waste Batteries Regulations aim to significantly increase UK collection and recycling of used portable batteries from 3% in 2007 to 25% by 2012, rising to at least 45% in 2016.

  • The battery symbol on a product or on its packaging indicates that the product must not be disposed of with general household waste. Instead, it is the consumer’s responsibility to dispose of their waste batteries at a designated collection point so that they can be recycled. The separate collection and recycling of batteries at the time of dispo sal will help to conserve natural resources and ensure that they are recycled in a manner that protects human health and the environment. A comprehensive list of battery recycling centres can be obtained from: www.recycle-more.co.uk

  • All Samsung products that are subject to the Batteries Directive are compliant with the UK battery and accumulator Requirements. In accordance with national law, SAMSUNG Electronics (UK) Ltd is a member of an approved batteries producer compliance scheme. This scheme collects, treats and disposes of batteries on Samsung’s behalf.

MAX-DA54T

Features

  • imagine the simple sound enriching your life

USB host play

USB host play
You get instant entertainment through USB with SAMSUNG Audio System. SAMSUNG Audio systems are the world’s first USB Host Audio Systems. Simply connect USB storage device into your SAMSUNG Audio System, and play various multimedia files: JPEG images, MP3, DivX, WMA, WMV etc.

AUX-IN

AUX-IN
The Front AUX-IN allows you to easily connect various portable audio devices such as MP3P, MID, Walkman and many others and comes standard on all SAMSUNG HDTVs. It is conveniently positioned on the front side for easy usage.

powerful sound

SAMSUNG Audio Systems give you min-blowing sound output. They come empowered with Dual Woofer for bass boost sound/ 2 rear cabinets to reduce the distortion and give you loud and crystal clear music.

tech specs

Dimension of MAX-DA54T/XME

Tuner

  • FM

    Yes (No-RDS)

  • AM

    No

  • LW

    No

  • THD (Mono)

    0.3%

  • THD (Stereo)

    0.5%

  • 75Ω Jack

    (OP)

  • Preset Memory

    30

Speaker

  • Type

    2 SPK

  • Impedance (Ω)

    4 Ohm

  • Active Subwoofer

    No

  • Surround

    No

SHOW MORE SPECSExpand

Display

  • Display

    2C-FLT (AC)

AMP

  • RMS (THD10%), 1 Ch

    50W/CH

  • PMPO

    1,100W

  • Spectrum Analizer

    No

  • Jog Dial

    Yes

  • Max BASS

    No

  • Dimmer/Demo

    Yes / Yes

  • Communication LED

    Yes

  • S.Bass

    No

  • Loop Dance

    No

  • Power Surround XT/Power Surround/Sound

    No / No / Yes

  • Timer/Clock/Sleep

    Yes / Yes / Yes

  • Frequency Range

    20Hz - 20KHz

Audio Features

  • EQ

    6 MODE

Tape

  • Deck Type

    2 Logic

  • Auto Reverse

    AUTO STOP

  • Auto Reverse Recording

    No

  • Tape Counter

    No

  • A.M.P.S

    No

  • Rec. Lock

    No

  • Hi-Speed Dubbing

    No

  • Dolby

    No

Terminals

  • Composite

    Yes

Connectivity

  • Aux

    3.5Φ

  • Headphone Out

    3.5Φ

  • Digital Out

    No

  • DC Jack

    No

  • Component Input

    Yes

  • SCART

    Option

  • Multi-Card Slot

    No

Remocon Key Number

  • Remocon Key Number

    58 Key

Karaoke

  • Mic Volume

    Yes (Option)

  • Mic Echo

    Yes (Option)

Option (Karaoke)

  • KEYCON

    No

  • 2-MIC

    1MIC (Option)

USB Host

  • PLAY

    Yes

  • MP3

    Yes

Dimension & Weight

  • Set Net Dimension (WxHxD)
    Set

    270 x 330 x 383mm

  • Front Speaker Net Dimension (1-Piece) (WxHxD)
    Front Speaker(1-Piece)

    220 x 330 x 205mm

  • Set Package Dimension (WxHxD)
    Set

    330 x 366 x 502mm

  • Front Speaker Package Dimension (WxHxD)
    Front Speaker

    515 x 390 x 275mm

  • Set Net Weight
    Set

    5.00kg

  • Speaker Net Weight
    Speaker

    5.00g

  • Speaker Package Weight
    Speaker

    6.15kg

  • Set Package Weight
    Set

    6.00kg

  • 1-Packing Weight

    12.50kg

  • 1-Packing Dimension (WxHxD)

    605 x 392 x 518mm

Loading Quantity

  • 40ft
    40ft

    510

  • 20ft
    20ft

    252

CD/DVDP

  • CDP Type

    3 DVD

  • Compatible Disc

    DVD, DivX, VCD, MP3-CD, WMA, CD-R / CD-RW

  • Repeat/Skip/Search

    Yes / Yes / Yes

  • Repeat a ↔ b

    Yes

  • Shuffle Play

    No

  • Program Play

    No

  • D/A Converter

    No

  • MP3 Decoder

    No

  • VCD

    No

  • Sound Type

    2 CH

  • Super Video

    No
