MAX-DA66T

MAX-DA66

For the person who's looking for a robust home entertainment system that's as elegant to look at as it is easy to use,they need look no further. With features such as easy connectivity to portable devices, prestigious design, the highest sound quality and HDMI, the digital compo is exactly what you ordered.

Recycling Batteries Responsibly

  • The European Directive on Batteries and Accumulators aims to minimise the impact of batteries on the environment and encourage the recovery of the materials they contain. In the UK, regulations on the recycling of batteries and accumulators (rechargeable batteries) were Introduced in 2009. The Waste Batteries Regulations aim to significantly increase UK collection and recycling of used portable batteries from 3% in 2007 to 25% by 2012, rising to at least 45% in 2016.

  • The battery symbol on a product or on its packaging indicates that the product must not be disposed of with general household waste. Instead, it is the consumer’s responsibility to dispose of their waste batteries at a designated collection point so that they can be recycled. The separate collection and recycling of batteries at the time of dispo sal will help to conserve natural resources and ensure that they are recycled in a manner that protects human health and the environment. A comprehensive list of battery recycling centres can be obtained from: www.recycle-more.co.uk

  • All Samsung products that are subject to the Batteries Directive are compliant with the UK battery and accumulator Requirements. In accordance with national law, SAMSUNG Electronics (UK) Ltd is a member of an approved batteries producer compliance scheme. This scheme collects, treats and disposes of batteries on Samsung’s behalf.

MAX-DA66T

Features

  • imagine bringing reality to home entertainment

HDMI out

HDMI out
HDMI (High Definition Multimedia Interface) eliminates the need for multiple cables. It is a digital connectivity standard capable of transmitting the highest quality uncompressed HD digital video & audio content, all through a single cable.

CD ripping

CD ripping
CD Ripping is powerful yet easy to use function that allows you to extract audio tracks directly from your music CDs. Just insert your CD and push the CD Ripping button.
USB Host

USB Host

The USB host features allows direct playback of music, pictures and video from USB devices to your SAMSUNG digital component. With USB host you no longer need to move contents to a PC and burn them into a CD or DVD before playback. Simply plug-in your digital camera, MP3 player or other USB devices to your SAMSUNG digital components and enjoy the contents immediately.
Portable Audio In

Portable Audio In

SAMSUNG’s ‘portable audio in’ allows you to easily connect with devices such as MP3, MD, Walkman and many others to play your contents. It is conveniently positioned on the front panel for ease of use.

tech specs

Dimension of MAX-DA66T/XME

Tuner

  • FM

    Yes

  • AM

    No

  • THD (Mono)

    0.3%

  • THD (Stereo)

    0.5%

  • 75Ω Jack

    Op

  • Preset Memory

    30

Speaker

  • Type

    2.1Spk

  • Impedance (Ω)

    4ohm / 3ohm

  • Active Subwoofer

    No

  • Surround

    No

SHOW MORE SPECSExpand

Display

  • Display

    2C-FLT (AC)

AMP

  • RMS (THD10%), 1 Ch

    260W/CH + 160W

  • PMPO

    7,500W

  • Jog Dial

    Yes

  • Max BASS

    No

  • Dimmer/Demo

    Yes / Yes

  • Communication LED

    Yes

  • S.Bass

    No

  • Loop Dance

    No

  • Power Surround XT/Power Surround/Sound

    No / No / Yes

  • Timer/Clock/Sleep

    Yes / Yes / Yes

  • Frequency Range

    20Hz - 20KHz

Audio Features

  • EQ

    3 Mode

Terminals

  • Composite

    Yes

Connectivity

  • Aux

    3.5phi

  • Headphone Out

    3.5phi

  • Digital Out

    No

  • DC Jack

    No

  • Component Input

    Yes

  • SCART

    No

  • Multi-Card Slot

    No

  • Bluetooth

    No

  • HDMI Input

    Yes (1,080i)

  • Wi-Fi

    No

  • Ethernet

    No

  • iPod Connection

    No

Karaoke

  • Mic Volume

    Yes (Option)

  • Mic Echo

    Yes (Option)

Option (Karaoke)

  • KEYCON

    No

  • 2-MIC

    No

USB Host

  • PLAY

    Yes

  • MP3

    Yes

Dimension & Weight

  • Sub Woofer Net Dimension (WxHxD)
    Woofer Speaker(1-Piece)

    238 x 346 x 280mm

  • Set Net Dimension (WxHxD)
    Set

    360 x 152 x 351mm

  • Front Speaker Net Dimension (1-Piece) (WxHxD)
    Front Speaker(1-Piece)

    220 x 361 x 286mm

  • Set Package Dimension (WxHxD)
    Set

    514 x 222 x 414mm

  • Front Speaker Package Dimension (WxHxD)
    Front Speaker

    514 x 422 x 351mm

  • Set Net Weight
    Set

    4.8kg

  • 1-Packing Dimension (WxHxD)

    753 x 502 x 516mm

Loading Quantity

  • 40ft
    40ft

    276

CD/DVDP

  • CDP Type

    1 DVD (Tray)

  • Compatible Disc

    DVD, DivX, (VCD), MP3-CD, WMA, CD-R/CD-RW

  • Repeat/Skip/Search

    Yes / Yes / Yes

  • Repeat a ↔ b

    Yes

  • Shuffle Play

    No

  • Program Play

    No

  • D/A Converter

    No

  • MP3 Decoder

    No

  • VCD

    No

  • Sound Type

    2.1CH

  • Super Video

    No

Support

User Manual

6.15 MB, pdf, ENGLISH

2008.07.01
