19" LED WES7 Thin Client Display (TS190W)

TS190W

The Samsung S Series is built with great features and capabilities. The S series is an innovative approach to display stand design due to its ability to house circuitry and other devices within its casing. This facilitates a slim design and minimises the amount of loose cables and wires. The S series can also be wall mounted, providing businesses with great versatility and interior design options. The S series model comes in three different screen sizes and two different models to suit individual business needs. 0 5 0 reviews

Recycling Batteries Responsibly

  • The European Directive on Batteries and Accumulators aims to minimise the impact of batteries on the environment and encourage the recovery of the materials they contain. In the UK, regulations on the recycling of batteries and accumulators (rechargeable batteries) were Introduced in 2009. The Waste Batteries Regulations aim to significantly increase UK collection and recycling of used portable batteries from 3% in 2007 to 25% by 2012, rising to at least 45% in 2016.

  • The battery symbol on a product or on its packaging indicates that the product must not be disposed of with general household waste. Instead, it is the consumer’s responsibility to dispose of their waste batteries at a designated collection point so that they can be recycled. The separate collection and recycling of batteries at the time of dispo sal will help to conserve natural resources and ensure that they are recycled in a manner that protects human health and the environment. A comprehensive list of battery recycling centres can be obtained from: www.recycle-more.co.uk

  • All Samsung products that are subject to the Batteries Directive are compliant with the UK battery and accumulator Requirements. In accordance with national law, SAMSUNG Electronics (UK) Ltd is a member of an approved batteries producer compliance scheme. This scheme collects, treats and disposes of batteries on Samsung’s behalf.

19" LED WES7 Thin Client Display (TS190W)

Features

  • 19” LED* Thin Client
  • S Series: All-in-one (circuitry in base of unit)
  • WES7 Embedded OS
  • AMD Ontario 1.0GHz Dual Core CPU
Remote management S/W

Remote management S/W

Samsung’s Cloud Display delivers amazing levels of convenience by using the remote management software of MagicRMS Pro. It delivers a centralised operation and saves administrators the time and hassle associated with physically having to visit each device for routine checks. Other benefits include virtually real-time device status monitoring, an inventory process and finally remote upgrading of firmware to all devices. With so many standout benefits for day-to-day operations, the MagicRMS software helps to make the office environment productive.
All-in-one design

All-in-one design

Samsung's innovative Cloud Display integrates a thin client into the LED* screen. Its contemporary and innovative design ensures that keeping your work environment clean and tidy is simple. The benefit of not having a separate thin client box is that you can use your desk space in a productive manner. These innovative features come together exceptionally for an all-in-one design that helps increase desktop space.

* Samsung’s LED displays utilise LCD Screens with LED edge lights.
Security you can trust

Security you can trust

Consolidate “almost all” of your resources on the data centre and deliver your applications and data over LAN/WAN via a number encrypted protocol including RDP, HDX and PColP to your thin client. Access your critical data and applications while they are maintained and controlled in the data centre
Little Maintenance

Little Maintenance

Because all software and data is stored on the centralised host platform, the network is easy to install and easy to maintain.

tech specs

Dimension of LF19TSWTBDN/XY

Display

  • Screen Size

    19"

  • Type

    LED Display

  • Brightness

    250cd/m²

  • Contrast Ratio

    1,000:1

  • Resolution

    1,440 x 900

  • Response Time

    5 minutes

  • Viewing Angle (Horizontal/Vertical)

    170° / 160°

  • Color Support

    16.7 Million

Interface

  • D-Sub

    1 ea

  • DVI

    1 ea

  • USB

    6 ea

  • Audio In/Out

    Headphone / line out, MIC in

  • Special

    RJ45

SHOW MORE SPECSExpand

General Feature

  • Embedded Function

    [OS] Windows Embedded Standard 7 (WES 7) [Client SW] - Microsoft RDP (7.1) - Citrix Online Plug-in (12.1) - VMWare (Vew 4.6) [Others] - Enhanced Write Filter (EWF) - Internet Explorer 8.0 - Media Player 12

  • Additional PC S/W

    Magic RMS Pro

  • Windows Certification

    Yes

  • Energy/Environment Mark

    TCO, Engergy Star

Design

  • Colour

    Black

  • Stand Type

    Swivel / Pivot / Height Adjustable

  • Wall Mount

    100 x 100

Power

  • Power Supply

    100 - 240V (50 / 60Hz)

  • Power Consumption

    Max: 45W, Typical: 25W

  • Power Consumption (Stand-by)

    2.7W

  • Type

    14V 4.5A 63W External Adapter

Dimension

  • Set Dimension with Stand (WxHxD)

    443.0 x 416.8 x 227.0mm

  • Set Dimension without Stand (WxHxD)

    443.0 x 301.9 x 49.5mm

  • Package Dimension (WxHxD)

    541 x 365 x 179mm

Weight

  • Set Weight with Stand

    4.42kg

  • Package Weight

    6.22kg

Accessory

  • Cables

    DVI, Power Cable, Power Cord

  • Others

    User Manual, Quick Setup Guide, Warranty Card

Support

User Manual

5.6 MB, pdf, ENGLISH

2012.07.12

Other Manuals (1)

  • Quick Guide

    6.07 MB, pdf, KOREAN, ENGLISH, ARABIC, CHINESE, CHINESE, FRENCH, GERMAN, HUNGARIAN, INDONESIAN, ITALIAN, JAPANESE, KAZAKH, POLISH, PORTUGUESE, RUSSIAN, SPANISH, SWEDISH, TURKISH

    2012.01.25

Driver (1)

  • Device(Install)

    Windows 7(32bit,64bit), 7.9 MB, exe, MULTI LANGUAGE

    Version : 1.0

    2012.01.30 tooltipbox

    Close tooltip pop-up
    1. Title
    Monitor Driver
    2. Applicable Model
    SyncMaster TS190W
    3. Carrier or Corporate Customer
    Open Market
    4. Description

    If you have trouble for setting up the Monitor under Windows 7, this program will help you to install Windows Monitor Driver. You can install the most suitable Windows driver for your monitor.

    System Requirements : Windows7(32bit/64bit)
