Samsung
Product Features
Brilliant Touch Screen With Infrared Technology
The enhanced sensitivity of the infrared touch screen makes the TSn-2 even easier to operate. Simply plug it in and the display is ready to go. The TSn-2 has a fast response time and a 3mm protective glass panel which gives you enhanced sensitivity, reliability and long operating hours.
RS232C In-Out
RS232C, a standard of serial communication, is used for the communication between PC and displays. Therefore, A Multiple Display Control (MDC), helping various displays to be easily and simultaneously operated on PC, is possible with RS232C function.
Specifications
Panel
- 32" Diagonal Panel Size
- 10000:1 Dynamic Contrast Ratio
- S-PVA (B-DID) Panel
- 1366 x 768(16:9) Display Resolution
- 0.511 x 0.511mm Pixel Pitch
- 697.6845 x 392.256mm Active Panel Display Area
- 450 cd/m2 Panel Brightness (Typical)
- 4000:1 Contrast Ratio
- Panel Viewing Angle: 178˚/178˚
- 8ms Panel Response Time
- 16.7 million (8 bit) Display Colors
- Color Garmut (0.72)
Connectivity
- Analog D-SUB, DVI-D
Display
- 30 - 81kHz H-scanning Frequency
- V-Scanning Frequency 56 - 85Hz
- 165 mHz Max Pixel Frequency
