Large Format Display

46" SL Series Specialised Display

SL46B

0 5 0 reviews

Recycling Batteries Responsibly

  • The European Directive on Batteries and Accumulators aims to minimise the impact of batteries on the environment and encourage the recovery of the materials they contain. In the UK, regulations on the recycling of batteries and accumulators (rechargeable batteries) were Introduced in 2009. The Waste Batteries Regulations aim to significantly increase UK collection and recycling of used portable batteries from 3% in 2007 to 25% by 2012, rising to at least 45% in 2016.

  • The battery symbol on a product or on its packaging indicates that the product must not be disposed of with general household waste. Instead, it is the consumer’s responsibility to dispose of their waste batteries at a designated collection point so that they can be recycled. The separate collection and recycling of batteries at the time of dispo sal will help to conserve natural resources and ensure that they are recycled in a manner that protects human health and the environment. A comprehensive list of battery recycling centres can be obtained from: www.recycle-more.co.uk

  • All Samsung products that are subject to the Batteries Directive are compliant with the UK battery and accumulator Requirements. In accordance with national law, SAMSUNG Electronics (UK) Ltd is a member of an approved batteries producer compliance scheme. This scheme collects, treats and disposes of batteries on Samsung’s behalf.

Layer Popup Close

Need more Info?

Request information about Samsung business products, solutions and services. We will contact you shortly.

Email Us BusinessUK@samsung.com

MAKE A REQUEST

At a Glance
  • The Samsung SL46B is the ideal solution for displaying your messages in most window display environments
  • With flexible and dynamic features, you can promote all the latest retail offers

Super High Brightness

Super High Brightness
The panel on Samsung Semi-Outdoor LFDs are extra bright for clear image and enhanced readability. Samsung LFDs are much brighter than conventional screen and deliver excellent visibility even under the brightest lighting conditions. With sharper and more vivid images your messages will attract more attention and break through the clutter.

Slim Bezel Maintains Image Smoothness

Slim Bezel Maintains Image Smoothness
The slim bezel of just 12mm removes any distractions from your sight to provide a greater surface area, which can be useful when creating a video wall in a shop window. It allows your content to shine through with less distractions or obstructions.

Sunglasses Free

Sunglasses Free
Because LCD panels use a polarized film, passers-by wearing sunglasses also coated in a polarized film can’t always see what was being displayed on the screen. The two polarized films cancelled each other out. But now Samsung have developed new panel coating that overcomes this problem – allowing everybody to see your message clearly.

Embedded Media Player

Embedded Media Player
In your day-to-day work it’s a constant challenge to make sure your sales or educational messages are noticed quickly, with maximum impact. With the built-in media player for your Samsung LFD, you can elevate your display capabilities more than you ever thought possible. Built within a microchip the media player has a CPU with a powerful processing speed and an impressive cache size. This means you can store and play advertisements, instructional films and animatics quickly and conveniently.

Full HD of 1929x1080 Resolution

Full HD of 1929x1080 Resolution
Samsung Semi-Outdoor LFD Full HD models are naturally eye catching and demand attention. The rich colour and dramatic depth of detail contained in the images provides the perfect platform for a high visibility, high impact digital display.

Configure to up to 100 Displays

Configure to up to 100 Displays
Ensure your customers see the best across multi screens. Digital loop out produces a single image without any loss of quality, and there’s no need for a separate video signal distributor. It’s easy to install and the most cost-effective way to connect multiple displays – up to an impressive 100 displays at once.

Built-in Speaker

Built-in Speaker
Maximise impact with a great picture twinned with ultra-crisp audio. The powerful built-in speakers will allow your message to be heard loud and clear while saving you the cost and space of having to purchase and install separate speakers.

High Performance Optional PC

High Performance Optional PC
Customise the content of your LFD solution with the optional Slide–in-Module (SIM) feature to meet your unique needs. Run content from a PC quickly and easily by simply sliding the PC in and out of the display without having to dismantle the unit from the wall.

Smart Scheduling

Smart Scheduling
Keep your display running efficiently at all times. This Samsung LFD boasts a smart scheduling feature. The automatic power on/off function allows you to designate time, day, volume, input source and holiday dates.

Multi Control via RJ45/RS232C

Multi Control via RJ45/RS232C
The Samsung Semi-Outdoor series features an upgraded Multi Display Control solution that lets you control a large number of displays through their embedded RS232 or RJ45 interfaces. Easy and intuitive to use, you can control displays over short and long distances.

Display Port Interface

Display Port Interface
The Samsung Semi-Outdoor series includes professional Display Port interface enables high performance multi-display control without the need for a distributor over longer distances. (2 times longer than DVI)
Optimised for Your 24/7 Business

Optimised for Your 24/7 Business

With Samsung’s innovative technology your message can be displayed 24 hours a day, 7 days a week. The Samsung Semi-Outdoor series utilises innovative cooling technology that improves heat dissipation while lowering internal temperatures. This allows you to run the LFD for 24 hours a day over longer periods without requiring costly servicing or maintenance.

Display

  • H-Scanning Frequency30 - 81 KHz
  • Maximum Pixel Frequency148.5 MHz
  • V-Scanning Frequency48 - 75 Hz

Panel

  • Diagonal Size46"
  • TypeS-PVA
  • Resolution1,920 x 1,080
  • Pixel Pitch(mm)0.53025 (H) x 0.53025 (V) mm
  • Active Display Area1,018.08 (H) X 572.67 (V) mm
  • Brightness1,500 cd/㎡
  • Contrast Ratio (Dynamic)10,000:1
  • Viewing Angle (Horizontal/Vertical)178 / 178 ° (CR > 10)
  • Response Time (G-to-G)8 ms
  • Display Colour16.7 M
  • Colour Gamut72 %
  • Contrast Ratio4,000:1
View remaining tech specs

Connectivity

  • Input

    • RGBD-SUB, DVI-D
    • VideoUSB, HDMI, CVBS, Component (by D-SUB)
    • AudioRCA(L/R) , Stereo Mini Jack
  • Output

    • RGBDVI-D (Loop-out)
    • VideoN/A
    • AudioStereo Mini Jack
    • Power OutN/A
  • External ControlRJ45, RS232C (In/Out)
  • External SensorAttached

Mechanical Specification

  • Dimension

    • Set Dimension (WxHxD)1,049.4 x 602.6 x 125 mm
    • Package Dimension (WxHxD)1,145 x 726 x 300 mm
  • Weight

    • Set Weight26.8 kg
    • Package Weight32.6 kg
  • VESA Mount600 x 400mm
  • Protection GlassN/A
  • Stand TypeN/A
  • Media Player Option TypeEmbedded, SIM (Slide in Module )

Operation

  • Operating Temperature0℃ - 30℃(Direct Sunlight)
  • Humidity10 - 80 %

General Features

  • KeyExtremely High Brightness
  • SpecialPlug and Play, MagicInfo Lite, Slide in Module, Digital Daisy Chains, Built in Speakers, Lamp Error Detection, Anti Image Retention, Temperature Sensor, RS232C/RJ45 MDC, PIP/PBP, Video Wall(10x10), Pivot Display, Button Lock, Smart Scheduling

Power

  • Energy Efficiency ClassN/A
  • Power SupplyAC 100 - 240 V~ (+/- 10 %), 50/60 Hz
  • Power Consumption

    • Off ModeLess than 1 W
    • On Mode440 W (Max) / 356 W (Typ)
    • Sleep ModeLess than 1 W
  • TypeInternal

Embedded PC

  • CPUN/A
  • N/BN/A
  • S/BN/A
  • GPUN/A
  • FDM/HDDN/A
  • MemoryN/A
  • EthernetN/A
  • Connectivity

    • USBN/A
    • OutputN/A
    • OthersN/A

Certification

  • EMCFCC (USA) FCC Part 15, Subpart B class A CE (Europe) EN55022, EN55024 VCCI (Japan) V-3 (CISPR22) KCC (Korea) :KN22, KN24 BSMI (Taiwan) : CNS13438 (CISPR22) C-Tick (Australia) : AS/NZS3548 (CISPR22) CCC(China) :GB 9254-2008, GB 17625.1-2003
  • EnvironmentN/A
  • SafetyUL (USA) : UL 60950-1 CSA (Canada) : CSA C22.2 No. 60950-1 TUV (Germany) : EN60950-1 NEMKO (Norway) : EN60950-1 KC (Korea) : K60950-1 CCC (China) : GB 4943-2001 PSB (Singapore) : IEC60950-1 GOST (Russia) : IEC60950-1, EN55022 SIQ (Slovenia) : IEC60950-1, EN55022 PCBC (Poland) : IEC60590-1, EN55022 NOM (Mexico) : NOM-019-SCFI-1993 IRAM (Argentina) :IEC60950-1 SASO (Saudi Arabia) : IEC60950-1

Accessory

  • IncludedQuick Setup Guide, Warranty Card, Application CD, Power Cord, Remote Controller, Batteries, D-Sub Cable
  • Optional

    • MountN/A
    • SpecialtyN/A
    • StandN/A
