Specifications

  • Cooling [Btu/h]

    30,700 Btu/h

  • Cooling (Min / Std / Max)

    9.0 kW

  • Type

    DUCT S

  • Indoor Unit

    AM090HNMPKH/EU

  • 1,2,220-240,50

  • Mode

    HP/HR

  • Cooling (Min / Std / Max)

    9.0 kW

  • Cooling [Btu/h]

    30,700 Btu/h

  • Heating (Min / Std / Max)

    10.0 kW

  • Heating [Btu/h]

    34,100 Btu/h

  • Cooling (Min / Std / Max)

    0.145 kW

  • Heating (Min / Std / Max)

    0.145 kW

  • Cooling 1)

    1.20 A

  • Heating 2)

    1.20 A

  • Type

    Sirocco Fan

  • Motor (Output) [W]

    153 x 1 W

  • Air Flow Rate (High / Mid / Low) [L/S]

    483.33/416.67/366.67

  • External Static Pressure (Min / Std / Max) [mmAq]

    0.00/4.00/15.00 mmAq

  • External Static Pressure (Min / Std / Max)

    0.00/39.23/147.10 Pa

  • Air Flow Rate (High / Mid / Low) [m3/h]

    1740/1500/1320 ㎥/h

  • Liquid Pipe (Φ, mm)

    9.52 mm

  • Liquid Pipe (Φ, inch)

    3/8"

  • Gas Pipe (Φ, mm)

    15.88 mm

  • Gas Pipe (Φ, inch)

    5/8"

  • Drain connection size

    VP25 (OD 32,ID 25)

  • Indoor (V)

    1.5 ~ 2.5

  • Outdoor (V)

    0.75 ~ 1.5

  • Type

    R410A(Contains fluorinated greenhouse gas, GWP=2,088)

  • Control Method

    EEV INCLUDED

  • Sound Pressure Level (Outdoor, High)

    38/35/32 dBA

  • Sound Power

    58.0 dBA

  • Net Weight (kg)

    33.0 kg

  • Shipping Weight (kg)

    38.5 kg

  • Unit Dimension (WxHxD)

    1200 x 250 x 700 mm

  • Shipping Dimension (WxHxD)

    1429 x 320 x 779 mm

  • Drain Pump

    MDP-G075SQ(built-in)MDP-G075SP(external)

  • Sound Pressure Level (Indoor, Low), dBA

    750 / 24

  • Sound Pressure Level (Indoor, Quiet Mode), dBA

    Removable/Wahable/Mildew proof
