Full outdoor Display OHN-S Series

back black, Full outdoor Display OHN-S Series

side black, Full outdoor Display OHN-S Series

r-perspective black, Full outdoor Display OHN-S Series

dynamic black, Full outdoor Display OHN-S Series

Full outdoor Display OHN-S Series

LH85OHNSLGB/ZA

Large displays optimized for DOOH
Unsurpassable visibility day and night
Easy-to-use management software

Choose your Pixel Pitch

85"

Large displays optimized for DOOH

The OHN series has elevated the typical outdoor advertising experience with its bold and engaging content delivery for any bus stop or street billboard. The OHN series will make any business standout from the crowd with its immersive and high-quality images and content.

Unsurpassable visibility day and night

The OHN series allows for exceptional, consistent content delivery with 3,000nit brightness and 24/7 performance. With a built-in dimming sensor, the display automatically adjusts the brightness based on the external lighting environment, saving display operating expenses and power consumption.

Easy-to-use management software

The embedded MagicINFO Player S6, backed by the powerful TIZEN operating system, boosts the display’s overall performance, allows for painless content management and ensures seamless transition and playback.

Built strong to endure impacts

The OHN series provides advanced safety through tempered Magic Protection Glass. It features durability that is IK10*-rated, further proving its robust level of strength that can endure physical impact.

*IK refers to effective protection against mechanical impacts. 10 indicates maximum protection from risk of impact that might damage equipment.

Resistant to outdoor elements

The OHN series is verified to perform in outdoor settings. IP56*-rated protection ensures the OHN series will withstand physical impact as well as dust, humidity or other outdoor elements that could affect the display.

*IP refers to levels of sealing effectiveness of electrical enclosures against intrusion from foreign bodies (tools, dirt etc.) and moisture. 5 refers to degree of protection from total dust ingress and 6 referring to degree of protected from low pressure water jets from any direction, limited ingress protection. **Image is for illustrative purposes only, specific application or program may have to be developed for the depicted usage scenario.

Specifications

Display

Diagonal Size 85"
Panel Type VA
Resolution 3,840 x 2,160
Pixel Pitch (HxV) 0.4875(H) x 0.4875(V)
Brightness 3,000nit
Contrast Ratio 3,000:1
Viewing Angle (H/V) 178/178
Response Time 8ms
Color Gamut 72 %
Glass Haze 0 %
H-Scanning Frequency 15~135KHz (HDMI), 30~135KHz (DP)
Maximum Pixel Frequency 594MHz (HDMI), 533.25MHz(DP)
V-Scanning Frequency 24~75Hz (HDMI), 30~75Hz (DP)
Contrast Ratio (Dynamic) 100,000:1

Connectivity

HDMI In 2
DP In 1
DVI In N/A
Tuner In N/A
USB 1
Component In N/A
Composite In N/A
RGB In N/A
IR In N/A
HDBaseT In N/A
HDBaseT Out N/A
Audio In N/A
Audio Out Stereo Mini Jack
Video Out N/A
Power Out N/A
RS232 In Stereo Mini Jack
RS232 Out N/A
RJ45 In Yes
RJ45 Out N/A
WiFi N/A
3G Dongle N/A
Bluetooth N/A

Power

Power Supply AC 100 - 240 V (+/- 10 %), 50/60 Hz
Power Consumption (Off Mode) N/A
Power Consumption (On Mode) 1800
Power Consumption (Sleep Mode) 0.5 W

Dimension

Set Dimension (WxHxD) 2004 x 1185 x 120 mm
Package Dimension (WxHxD) 2175 x 1383 x 495 mm

Weight

Set Weight 163 kg
Package Weight 211 kg

Operation Conditions

Temperature -30℃~50℃
Humidity 10 ~ 80%, non-condensing

Mechanical Specification

VESA Mount N/A
Bezel Width 62
Glass Thickness 5T
Glass Film AR, λ/4
Frame Material N/A

General Feature

External Memory Slot N/A

Optional Feature

Protection Glass Yes
Mount No
Stand No

Internal Player (MagicInfo)

MagicInfo Daisychain Videowall Support No

Eco

Energy Star (Latest effective version) N/A

Certification and Compliance

EMC FCC (USA) Part 15, Subpart B Class B
Safety CB (Europe) : IEC60950-1/EN60950-1 CCC (China) : GB4943.1-2011 PSB (Singapore ) : PSB+IEC60950-1 NOM (Mexico ) : NOM-001-SCFI-1993 IRAM (Argentina ) : IRAM+IEC60950-1 SASO (Saudi Arabia ) : SASO+IEC60950-1 BIS(India) : IEC60950-1 / IS13252 NOM(Mexico) : Tuner : NOM-001-SCFI-1993 Tunerless : NOM-019-SCFI-1998 KC(Korea) : K 60950-1 EAC(Russia) : EAC+IEC60950-1 INMETRO(Brazil) : INMETRO+IEC60950-1 BSMI(Taiwan) : BSMI+IEC60950-1 RCM(Australia) : IEC60950-1/AS/NZS 60950-1 UL(USA) : cUL60950-1 CSA (Canada) : cUL TUV (Germany) : CE NEMKO (Norway) : CE
