• Operation ON/OFF control
• Fan speed control
• Operation temperature setting
• Wind-Free™ Cooling function
• Filter replacement alarm reset
• Air swing control
• Simple ON/OFF timer
• Indoor unit option code setting
• Option/Setting selection

• 360 Cassette airflow direction control
• Operation ON/OFF control
• Fan speed control
• Operation temperature setting
• Filter replacement alarm reset
• Simple ON/OFF timer
• Indoor unit option code setting

• Simplifi ed wired remote controller
• AC operation ON/OFF control
• Fan speed control
• Setting operation mode and temperature
• Reset fi lter cleaning alert indicator
• Adjust airfl ow direction
• Operation ON/OFF timer function

• Bigger display: clear & bright backlight screen with big fonts
• Wind-Free™ button: control Wind-Free™ function with just one click
• Room temperature monitor and room temperature display thanks to the
built-in temperature sensor
• Icon/Function Lock: option of restricting icon/function on the display
• Sleep Mode: help users to sleep better by controlling temperature
• Outing Feature: keep room temperature above/below specific set value
when the user is out of the room

• Concealed wireless signal receiver
• Filter replacement sign
• Fan operation display
• Operation Timer setting display
• Operation ON/OFF button
• Operation On display LED (blue)
• Defrost operation display LED (red)

Air conditioner/ERV control
• AC control: ON/OFF, operation mode, temperature setting, fan speed, airflow direction
• ERV control: ON/OFF, operation mode, fan speed
• AC/ERV error monitoring
• Filter cleaning alert and reset alert time
• Control a maximum of 16 “Indoor unit + ERV” in a group with a single wired
controller

Energy saving operation
• Upper/lower temperature limit setting
• Automatically stops operating when not used for certain period of
time as set by user
Weekly operation schedule setting
• Weekly operating schedule (A/C only, ERV only, A/C+ERV)
• Set desired AC operation mode, temperature and fan speed to operate based on a weekly schedule
• Apply schedule exception day
• Energy consumption monitoring (MWR-WG00*N)
• Operation time limit (MWR-WG00*N)
User convenience function
• Child lock
• Different button permission levels
• Room temperature display (MWR-WG00*N)
• Dual set point (MWR-WG00*N)
• Built-in room temperature sensor
• Real-time clock: displays current time and day (summer time support)
• Multiple language support
• Service mode support
‐ Indoor unit cycle data monitoring
‐ Indoor unit option code setting and monitoring
‐ Indoor unit address setting and monitoring (MWR-WG00*N)
‐ SD card slot (MWR-WG00*N)

• Maximum 16-group controller (Max. 128 units)
• Whole/Group/Individual indoor unit control (ON/OFF)
• Restriction on the use of wireless/wired remote controllers and external contact control
• Cooling and heating mode control
• Indoor unit error display

• 7-inch touch LCD controller
• Controls a maximum of 128 indoor units
• Controls a maximum of 12 zones
• Schedule control, Indoor unit usage restriction, View indoor unit error history

• Controls and monitoring system air conditioner by mobile phone. (Max. 16 units)
• Weekly schedule setting
• Group control and monitoring (ON/OFF)
• Current/daily/weekly/monthly energy usage data of outdoor unit. (This function is available in certain outdoor unit models)

• DVM CHILLER ON/OFF control (Module/Group)
• Operation mode, water outlet temperature setting
• Optional operation setting
• Module/Group setting
• Weekly operation schedule setting

With the BMS control and monitoring function, BACnet gateway makes it easy to control the air conditioning network in various ways. BACnet gateway can control up to 256 indoor units, used in combination with S-NET 3.
• Interface for BACnet management system
• Maximum of 256 indoor units plus ERVs, supported by a maximum of 80 interface modules
• Includes DMS 2.5 functions

LonWorks gateway is an interface for Lon-Connection to the LonWorks management system, providing you with a more convenient way to manage your air conditioning system. It can control a maximum of 128 indoor units, used in combination with S-NET 3.
• Exclusive use for DMS 2.5 power distribution
• Connection with up to eight watt-hour meters
• Pulse interface with watt-hour meters
• Watt-hour meter - by third party

Samsung Guestroom Management System saves users the energy and money wasted on cooling an unoccupied room.
The air conditioner is activated when the Key-Tag is in place and turns off when the Key-Tag is removed. An external contact interface module provides direct indoor unit control via an external contact signal, as well as window-synchronised indoor unit control. The emergency control function features simple contact input. The module also generates indoor unit operation/error state output through relay contacts.
• Direct indoor unit control by external contact signal
• Window-synchronised indoor unit control
• Emergency control with simple contact input
• Indoor unit operation/error state output through relay contacts

• The Watt-Hour Meter Interface Module can be exclusively used for DMS 2.5 power distribution, displaying power consumption for each watt-hour meter.
• Exclusive use for DMS 2.5 power distribution
• Connection with up to eight watt-hour meters
• Pulse interface with watt-hour meters
• Watt-hour meter - by third party

• Communication interface module between outdoor units and the upper level controller which makes use of a different type of communication
• Connect one interface module to one outdoor unit
• Individual control - maximum of 48 indoor units
• Group control - maximum of 16 groups
• Automatic detection of communication type: determine the communication type used by the upper level controller according to the communication type used by the outdoor unit
• Supported communication type
‐ Conventional outdoor unit communication ←→ New upper
level controller communication
‐ New outdoor unit communication ←→ Conventional upper
level controller communication

• Communication interface module between new communication ERV and controller
• Connect one ERV interface module to a maximum of 16 ERVs
• Individual control - maximum of 16 ERVs
• Group control - maximum of 16 groups
• Supported communication type
‐ Conventional ERV communication ←→ New upper level
controller communication
‐ New ERV communication ←→ Conventional upper level
controller communication
‐ New ERV communication ←→ New upper level controller
communication

• Communication interface module
• Connect one FCU interface module to a maximum of 16 FCU Kits.
• Supports FCU Kit only
