Headlamp Solutions

Lighting the way for future mobility

Headlamp Solutions

Lighting the way for future mobility

C-series Gen3

Boost
Headlamp
Energy
Performance

As the electric vehicle market continues to expand, maximizing battery performance has become critical. In meeting the growing need to reduce battery consumption and improve overall vehicle efficiency, demand for lighter and more efficient components has increased substantially. The energy-conserving LEDs stand out as the perfectly suited lamp solutions for EV markets.

LEARN MORE
 
U-series

Unlimited
Design
Flexibility

As headlamps are often thought of as the “eyes” of an automobile, their indigenous design can convey a brand’s identity, as well as highlight a vehicle’s innovative technology. In an effort to create more stand out and unique designs, the demand for compact lamp components is increasing. LEDs with superior luminance, leading to simplified optic systems, are the ideal solution for improving design freedom.

LEARN MORE
 
T-series

Improving
Accessibility for
LED Headlamps

LEDs enable more energy efficient and sleek headlamp design. However, LED headlamps are often found to be more expensive than conventional halogen lamps, hindering their widespread adoption. To increase the accessibility for LED headlamps, cost-effective LED solutions are important.

LEARN MORE
 

C-series Gen3

product selection guide detail
Product Key Features Efficacy
(lm/W)
Lifespan
[Gen3] 3W White
  • · PKG Size (L x W x H) : 1.50 x 1.90 x 0.77 mm
  • · Typ. 410lm, 3.0V @ 1A, 25℃, T2 (0.32,  0.33)
  • · Rth_J-S (Elec) 2.5 K/W, Rth_J-S (Real) 3.8 K/W
[Gen3] 6W White
  • · PKG Size (L x W x H) : 2.66 x 3.10 x 0.77 mm
  • · Typ. 808lm, 6.0V @ 1A, 25℃, T2 (0.32,  0.33)
  • · Rth_J-S (Elec) 1.5 K/W, Rth_J-S (Real) 2.2 K/W
[Gen3] 9W White
  • · PKG Size (L x W x H) : 3.76 x 3.10 x 0.77 mm
  • · Typ. 1212lm, 9.0V @ 1A, 25℃, T2 (0.32,  0.33)
  • · Rth_J-S (Elec) 1.0 K/W, Rth_J-S (Real) 1.4 K/W
[Gen3] 12W White
  • · PKG Size (L x W x H) : 4.86 x 3.10 x 0.77 mm
  • · Typ. 1615lm, 12.0V @ 1A, 25℃, T2 (0.32,  0.33)
  • · Rth_J-S (Elec) 0.8 K/W, Rth_J-S (Real) 1.1 K/W

U-series

product selection guide detail
Product Key Features Efficacy
(lm/W)
Lifespan
[Gen1] 5W White
  • · PKG Size (L x W x H) : 1.50 x 1.90 x 0.77 mm
  • · Typ. 425lm, 3.3V @ 1.5A, 25℃, T2 (0.32,  0.33)
  • · Rth_J-S (Elec) 4.3 K/W, Rth_J-S (Real) 5.5 K/W
[Gen1] 10W White
  • · PKG Size (L x W x H) : 2.46 x 3.10 x 0.77 mm
  • · Typ. 842lm, 6.6V @ 1.5A, 25℃, T2 (0.32,  0.33)
  • · Rth_J-S (Elec) 2.5 K/W, Rth_J-S (Real) 3.4 K/W
[Gen1] 15W White
  • · PKG Size (L x W x H) : 3.28 x 3.10 x 0.77 mm
  • · Typ. 1262lm, 9.9V @ 1.5A, 25℃, T2 (0.32,  0.33)
  • · Rth_J-S (Elec) 1.8 K/W, Rth_J-S (Real) 2.4 K/W

T-series

product selection guide detail
Product Key Features Efficacy
(lm/W)
Lifespan
[Gen1] 6W White
  • · PKG Size (L x W x H) : 3.50 x 3.75 x 0.729 mm
  • · Typ. 830lm, 6.30V @ 1.0A, 25℃, R2 (0.33, 0.35)
  • · Rth_J-B (Elec) 1.5 K/W, Rth_J-B (Real) 2.2 K/W
[Gen1] 9W White
  • · PKG Size (L x W x H) : 4.60 x 3.75 x 0.729 mm
  • · Typ. 1244lm, 9.45V @ 1.0A, 25℃, R2 (0.33, 0.35)
  • · Rth_J-B (Elec) 1.1 K/W, Rth_J-B (Real) 1.6 K/W
[Gen1] 12W White
  • · PKG Size (L x W x H) : 5.70 x 3.75 x 0.729 mm
  • · Typ. 1659lm, 12.6V @ 1.0A, 25℃, R2 (0.33, 0.35)
  • · Rth_J-B (Elec) 0.8 K/W, Rth_J-B (Real) 1.2 K/W
