Turn Signal

Samsung LEDs turn signal illuminating orange light.

Highly Conspicuous Light
with Sleek Design

Compact Size with Performance Gives Your Vehicle a Stylish Look

Complying with intensity requirements in small form emits
eye-catching light while allowing design freedom to add a sleek touch

Samsung LEDs a turn signal light illuminating a yellow light on the black squared car

Fx Series

product selection guide detail
Product Key Features Efficacy
(lm/W)
Lifespan
1W Amber
  • · Luminous Flux : 85 lm @ 350 mA
  • · Forward Voltage : 3.0 V
  • · Thermal Resistance: 6.0 K/W (Rth J-S elec.)
3W Amber
  • · Luminous Flux : 210 lm @ 1,000 mA
  • · Forward Voltage : 3.0 V
  • · Thermal Resistance: 4.5 K/W (Rth J-S elec.)

C Series

product selection guide detail
Product Key Features Efficacy
(lm/W)
Lifespan
[Gen1] 1W Bi-Color
  • · PKG Size (L x W x H) : 3.00 x 2.00 x 0.86 mm
  • · White : Typ. 120lm, 3.2V @ 350mA, 25℃, R2 (0.33,  0.35)
  • · Amber : Typ. 75lm, 3.2V @ 350mA, 25℃, A0 (0.57,  0.42)
[Gen2] 3W Amber
  • · PKG Size (L x W x H) : 1.50 x 1.90 x 0.77 mm
  • · Typ. 235lm, 3.0V @ 1A, 25℃, A0 (0.57,  0.42)
  • · Rth_J-S (Elec) 3.0 K/W, Rth_J-S (Real) 3.7 K/W

P Series

product selection guide detail
Product Key Features Efficacy
(lm/W)
Lifespan

S Series

product selection guide detail
Product Key Features Efficacy
(lm/W)
Lifespan
[Gen1] 0.7W Amber
  • · PKG Size (L x W x H) : 2.30 x 2.30 x 0.55 mm
  • · Typ. 60lm, 2.9V @ 200mA, 25℃, A0 (0.57,  0.42)
  • · Rth_J-S (Elec) 6.2 K/W, Rth_J-S (Real) 8.0 K/W
