Enrich Your Space with Lights

Samsung LEDs special technology and exceptional quality will fulfill every possible lighting need for any space you demand

Samsung LEDs spaceous office bright with ceiling light turned on.

Encounter Illumination Comfort

Area Lighting Maximized for Visual Comfort

Exclusively designed for homes, office spaces and commercial zones, Samsung LEDs helps the ambience of space to be more comfortable for your eyes

Samsung LEDs an empty conference room lighted up with ambient lights

Product Selection Guide (LED Components)

product selection guide detail
Product Key Features Efficacy
(lm/W)
Lifespan
LM281BA+
  • 0.2W, 3V mid power LED
  • Luminous Flux: 26.5 lm @ 60 mA
  • Luminous Efficacy: 150 lm/W
LM281B+
  • 0.5W, 3V mid power LED
  • Luminous Flux: 73 lm @ 150 mA
  • Luminous Efficacy: 165 lm/W
LM301B
  • 0.2 W, 3 V mid power LED
  • Luminous Flux: 39.3 lm @ 65 mA
  • Luminous Efficacy: 223 lm/W
LM301Z+
  • 0.2 W, 3 V mid power LED
  • Luminous Flux: 36.2 lm @ 65 mA
  • Luminous Efficacy: 205 lm/W
LM301Z
  • 0.2 W, 3 V mid power LED
  • Luminous Flux: 34.5 lm @ 65 mA
  • Luminous Efficacy: 195 lm/W
LM302C
  • 0.4 W, 6 V mid power LED
  • Luminous Flux: 66.9 lm @ 65 mA
  • Luminous Efficacy: 181 lm/W
LM561B Plus
  • 0.2 W, 3 V mid power LED
  • Luminous Flux: 36 lm @ 65 mA
  • Luminous Efficacy: 192 lm/W
LM561C
  • 0.2 W, 3 V mid power LED
  • Luminous Flux: 38 lm @ 65 mA
  • Luminous Efficacy: 210 lm/W

Product Selection Guide (Modules)

product selection guide detail
Product Key Features Efficacy
(lm/W)
Lifespan
H Series Gen3
  • High performance
  • 187 lm/W @ 4000K
  • Size: 275 / 560 / 1120 mm
S Series
  • High voltage solution
  • 170 lm/W @ 4000K
  • Size: 275 / 560 / 1120 mm
M Series Gen2
  • Platform & Flexible design choices
  • 158 lm/W @ 4000K
  • Size: 91 / 275 / 560 / 1120 mm
V Series
  • Low-end solution
  • 146 lm/W @ 4000K
  • Size: 140 / 280 / 560 mm
Q Series
  • Highest performance
  • 203 lm/W @ 4000K
  • Size: 275 / 560 / 1120 mm

Unique Space Atmosphere

Downlights with Advanced Color Technology

Samsung LEDs offers ultimate color rendering and consistency optimized for recessed lights, pendants and surface-mounted lights to beautify various spaces

Samsung LEDs a living room lighted up with diffirent types of indoor lights

Product Selection Guide (LED Components)

product selection guide detail
Product Key Features Efficacy
(lm/W)
Lifespan
LM282B+
  • 0.9 W, 6 V mid power LED
  • Luminous Flux: 118 lm @ 150 mA
  • Luminous Efficacy: 128 lm/W
LM283B+
  • 0.9 W, 9 V mid power LED
  • Luminous Flux: 120 lm @ 100 mA
  • Luminous Efficacy: 133 lm/W
LM283BS+
  • 0.5 W, 9 V mid power LED
  • Luminous Flux: 61.5 lm @ 60 mA
  • Luminous Efficacy: 113 lm/W
LM286B+
  • 0.9 W, 18 V mid power LED
  • Luminous Flux: 85 lm @ 50 mA
  • Luminous Efficacy: 94 lm/W
LM301B
  • 0.2 W, 3 V mid power LED
  • Luminous Flux: 39.3 lm @ 65 mA
  • Luminous Efficacy: 223 lm/W
LM301Z+
  • 0.2 W, 3 V mid power LED
  • Luminous Flux: 36.2 lm @ 65 mA
  • Luminous Efficacy: 205 lm/W
LM301Z
  • 0.2 W, 3 V mid power LED
  • Luminous Flux: 34.5 lm @ 65 mA
  • Luminous Efficacy: 195 lm/W
LM302C
  • 0.4 W, 6 V mid power LED
  • Luminous Flux: 66.9 lm @ 65 mA
  • Luminous Efficacy: 181 lm/W
LM302Z
  • 0.9 W, 6 V mid power LED
  • Luminous Flux: 134.7 lm @ 150 mA
  • Luminous Efficacy: 145 lm/W
LM561B Plus
  • 0.2 W, 3 V mid power LED
  • Luminous Flux: 36 lm @ 65 mA
  • Luminous Efficacy: 192 lm/W
LM561C
  • 0.2 W, 3 V mid power LED
  • Luminous Flux: 38 lm @ 65 mA
  • Luminous Efficacy: 210 lm/W
LH351B
  • Wattage (Max) : 4.7 W @ 1.5 A
  • Luminous Flux: 165 lm @ 350 mA
  • Luminous Efficacy: 172 lm/W
LH351C
  • Wattage (Max) : 6.0 W @ 2.0 A
  • Luminous Flux: 316 lm @ 700 mA
  • Luminous Efficacy: 160 lm/W
LC010C
  • 10 W small LES COB LED
  • 3-step MacAdam ellipse
  • Size: 13.5 x 13.5 mm
LC020C
  • 20 W small LES COB LED
  • 3-step MacAdam ellipse
  • Size: 19.0 x 19.0 mm
LC030C
  • 30 W small LES COB LED
  • 3-step MacAdam ellipse
  • Size: 19.0 x 19.0 mm
LC040C
  • 40 W small LES COB LED
  • 3-step MacAdam ellipse
  • Size: 19.0 x 19.0 mm
LC013D
  • 13 W class COB LED
  • 2, 3-step MacAdam ellipse
  • Size: 13.5 x 13.5 mm
LC016D
  • 16 W class COB LED
  • 2, 3-step MacAdam ellipse
  • Size: 19.0 x 19.0 mm
LC019D
  • 19 W class COB LED
  • 2, 3-step MacAdam ellipse
  • Size: 19.0 x 19.0 mm
LC026D
  • 26 W class COB LED
  • 2, 3-step MacAdam ellipse
  • Size: 19.0 x 19.0 mm
LC033D
  • 33 W class COB LED
  • 2, 3-step MacAdam ellipse
  • Size: 19.0 x 19.0 mm
LC013D PC
  • 13 W premium color COB LED
  • HCRI, Vivid Color, Special Color
  • Size: 13.5 x 13.5 mm
LC016D PC
  • 16 W premium color COB LED
  • HCRI, Vivid Color, Special Color
  • Size: 19.0 x 19.0 mm
LC019D PC
  • 19 W premium color COB LED
  • HCRI, Vivid Color, Special Color
  • Size: 19.0 x 19.0 mm
LC026D PC
  • 26 W premium color COB LED
  • HCRI, Vivid Color, Special Color
  • Size: 19.0 x 19.0 mm
LC033D PC
  • 33 W premium color COB LED
  • HCRI, Vivid Color, Special Color
  • Size: 19.0 x 19.0 mm
LC040D PC
  • 40 W premium color COB LED
  • HCRI, 2, 3-step MacAdam ellipse
  • Size: 28.0 x 28.0 mm
LM101A
  • 0.5 W, 3 V mid power CSP
  • 67 lm @ 150 mA
  • Size: 1.15 x 1.15 mm
LM102A
  • 0.9 W, 6 V mid power CSP
  • 124 lm @ 150 mA
  • Size: 1.30 x 1.30 mm
LH181A
  • Wattage (Max) : 4.5 W @ 1.5 A
  • Luminous Flux: 160 lm @ 350 mA
  • Size: 1.91 x 1.91 mm

Product Selection Guide (Modules)

product selection guide detail
Product Key Features Efficacy
(lm/W)
Lifespan
ACOM
  • Easy installation
  • 100 lm/W @ 4000K
  • Size: 55 x 55 mm
Round Gen3
  • Cost saving by minimizing heat-sink
  • 152 lm/W @ 4000K
  • Diameter: 90 / 110 / 130 mm

Dazzling Product Presentation

Spotlights with Compact Design and Robust Luminosity

Samsung LEDs excellent colors and strong light power enables refined product displays in retail stores, boutiques, and galleries

Samsung LEDs a white gallery where bright spot lights are shining over each art displays respectively

Product Selection Guide (LED Components)

product selection guide detail
Product Key Features Efficacy
(lm/W)
Lifespan
LM301Z+
  • 0.2 W, 3 V mid power LED
  • Luminous Flux: 36.2 lm @ 65 mA
  • Luminous Efficacy: 205 lm/W
LM301Z
  • 0.2 W, 3 V mid power LED
  • Luminous Flux: 34.5 lm @ 65 mA
  • Luminous Efficacy: 195 lm/W
LC010C
  • 10 W small LES COB LED
  • 3-step MacAdam ellipse
  • Size: 13.5 x 13.5 mm
LC020C
  • 20 W small LES COB LED
  • 3-step MacAdam ellipse
  • Size: 19.0 x 19.0 mm
LC030C
  • 30 W small LES COB LED
  • 3-step MacAdam ellipse
  • Size: 19.0 x 19.0 mm
LC040C
  • 40 W small LES COB LED
  • 3-step MacAdam ellipse
  • Size: 19.0 x 19.0 mm
LC013D
  • 13 W class COB LED
  • 2, 3-step MacAdam ellipse
  • Size: 13.5 x 13.5 mm
LC016D
  • 16 W class COB LED
  • 2, 3-step MacAdam ellipse
  • Size: 19.0 x 19.0 mm
LC019D
  • 19 W class COB LED
  • 2, 3-step MacAdam ellipse
  • Size: 19.0 x 19.0 mm
LC026D
  • 26 W class COB LED
  • 2, 3-step MacAdam ellipse
  • Size: 19.0 x 19.0 mm
LC033D
  • 33 W class COB LED
  • 2, 3-step MacAdam ellipse
  • Size: 19.0 x 19.0 mm
LC013D PC
  • 13 W premium color COB LED
  • HCRI, Vivid Color, Special Color
  • Size: 13.5 x 13.5 mm
LC016D PC
  • 16 W premium color COB LED
  • HCRI, Vivid Color, Special Color
  • Size: 19.0 x 19.0 mm
LC019D PC
  • 19 W premium color COB LED
  • HCRI, Vivid Color, Special Color
  • Size: 19.0 x 19.0 mm
LC026D PC
  • 26 W premium color COB LED
  • HCRI, Vivid Color, Special Color
  • Size: 19.0 x 19.0 mm
LC033D PC
  • 33 W premium color COB LED
  • HCRI, Vivid Color, Special Color
  • Size: 19.0 x 19.0 mm
LC040D PC
  • 40 W premium color COB LED
  • HCRI, 2, 3-step MacAdam ellipse
  • Size: 28.0 x 28.0 mm
LM101B
  • 0.5 W, 3 V mid power CSP
  • 67 lm @ 150 mA
  • Size: 1.70 x 1.70 mm
LH181B
  • Wattage (Max) : 4.5 W @ 1.4 A
  • Luminous Flux: 173 lm @ 350 mA
  • Size: 2.36 x 2.36 mm
LH231B
  • Wattage (Max) : 6.0 W @ 2.0 A
  • Luminous Flux: 337 lm @ 700 mA
  • Size: 2.80 x 2.80 mm

Product Selection Guide (Modules)

product selection guide detail
Product Key Features Efficacy
(lm/W)
Lifespan
ACOM
  • Easy installation
  • 100 lm/W @ 4000K
  • Size: 55 x 55 mm
Round Gen3
  • Cost saving by minimizing heat-sink
  • 152 lm/W @ 4000K
  • Diameter: 90 / 110 / 130 mm
