FJM Wall-mount duct with Wind-Free™ Cooling

FJM Wall-mount duct with Wind-Free™ Cooling

AJ026TNLPKH/EA

  • Flexible Installation
  • 199mm Height
  • Anti Virus Filter

Choose your Color

  • Flexibly fits & blends into more places
    2-way Air Inlet
  • Blends in with a compact & elegant design
    Slim & Compact Design (199mm Height)
  • Automatically monitor filter cleanliness
    Easy Filter Cleaning

Flexibly fits & blends into more places

2-way Air Inlet

Install your air conditioner in a wide variety of locations. It has a 2-way air inlet – bottom or rear – that gives you much more flexibility in selecting an installation location. It can be configured to provide the optimum airflow to almost any room, while being concealed behind ceilings.

Bottom Side
Rear Side

Blends in with a compact & elegant design

Slim & Compact Design (199mm Height)

Enhance the look and feel of almost any space. Being 199mm high and 700mm* wide, its slim and compact design is highly elegant, so it can be discretely concealed in many locations. It also makes installation, maintenance and repair quick and easy, so it’s ideal for a wide range of businesses.

* Based on the AM036KNLDEH/EU model. The width of other models may vary.

Automatically monitor filter cleanliness

Easy Filter Cleaning

Maintain your air conditioner easily and cost-effectively. The filter cleaning indicator automatically notifies you when the filter is due for cleaning after 1,000 hours of operation*. The design of the duct system makes this very simple, so it reduces maintenance time and its financial impact.

* 1,000 hours is the default setting, but this can be adjusted to 2,000 hours on the internal PCB.

Simple set up, automatically even cooling

Smart Pressure Control

Enjoy maximum comfort and efficiency with minimum effort. The Smart Pressure Control automatically optimizes the air volume and pressure and minimizes noise, ensuring consistent cooling and heating in any situation. The external static pressure (ESP) can also be adjusted using a remote control

Flexible installation in more locations

Optional High Lift-Up Drain Pump

Enjoy a greater choice of installation locations and maintain it conveniently. An optional High Lift-Up Drain Pump lifts condensed water up to 750mm, compared with the previous limit of 700mm. And you can check, repair or install a new drain pump by simply removing the right-side panel.

Specifications

Download
  • Cooling [Btu/h] 8,900 Btu/h
  • Cooling [kW] 2.6 kW
  • Panel Net Weight (kg) 15.0 kg
  • Net Dimensions (WxHxD) (mm) 700 x 199 x 440 mm
