UDD Series 55"

LH55UDDPLBB/XY

  • Provide seamless viewing with unprecedented 3.5mm bezel width

Choose your Size

UDD Series 55"

55"
Provide seamless viewing with unprecedented 3.5mm bezel width Provide seamless viewing with unprecedented 3.5mm bezel width

Provide seamless viewing with unprecedented 3.5mm bezel width

Provide seamless viewing with unprecedented 3.5mm bezel width

Samsung UD55D LFDs with FHD can take your digital messaging to the next level thanks to unsurpassed Samsung bezel innovation. 36% more narrow than the existing UD55C, and unrivalled among all competitors, these never before seen 3.5mm bezel displays can amaze audiences when combined together to form seamless video walls with virtually no visual distraction. From 4 meters (13 feet) away UD55D bezels are invisible to the naked eye creating a truly uninterrupted image for optimized visual messaging. Use this cutting-edge display technology to entice customers into your retail shop, replace traditional whiteboards in your corporate meeting room or provide important real-time information in public places. Additionally, provide highly bright, vibrant picture quality without glare or blurriness to completely captivate audiences with a powerful viewing experience. * Incomparable 3.5mm bezel width : Market-leading 3.5mm ultra-narrow bezels (bezel to bezel) enable displays to deliver seamless, impressive images and superior brand experience * Enhanced picture quality : Full-HD resolution with new backlit dimming solution to improve contrast along with improved contrast ratio create outstanding picture quality * Innovative anti-glare panels : Anti-glare panels prevent dazzling glare from disrupting the view along with Anti-retention to reduce haze by 44%

Amaze your viewers with accurate color across multiple displays Amaze your viewers with accurate color across multiple displays

Amaze your viewers with accurate color across multiple displays

Amaze your viewers with accurate color across multiple displays

Deliver your messages in consistently accurate color across multiple displays with Samsung UD55D LFDs. The displays undergo a meticulous factory color calibration process, ensuring accurate color without image distortion without the need for manual calibration. The improved factory color-tuning for white balancing and color difference compensation ensure that the displays present image in uniform color with color temperature matching. For users who want to fine-tune the colors, Samsung Advanced Color Management offers more detailed management. Color vibrancy can be calibrated automatically or manually. Color values can be shared between multiple displays, ensuring outstanding intensity across all video wall screens that can impress the audience. Combined with the anti-glare panel that reduces light scatter to make messages more readable, UD55D LFDs can effectively deliver your content in the vibrant, accurate color to impress your audience.

Create, display, and manage with ease using Samsung Smart Signage Platform Create, display, and manage with ease using Samsung Smart Signage Platform

Create, display, and manage with ease using Samsung Smart Signage Platform

Create, display, and manage with ease using Samsung Smart Signage Platform

The built-in Samsung Smart Signage Platform (SSSP) solution eliminates the need to purchase an additional PC for each display in a video wall. SSSP supports the MagicInfo VideoWall application that can play content created in the VideoWall authoring program or console applications. The embedded MagicInfo™ VideoWall S Player enables the easy display of video walls up to 4 x 4 without the need for additional PCs, video wall player software, or expensive video wall processor.

Display content optimally with easy image rotation Display content optimally with easy image rotation

Display content optimally with easy image rotation

Display content optimally with easy image rotation

Whether using a single display or a video wall, you can create content in portrait or landscape mode—and then rotate it. Samsung displays include a pivot and Image Rotation function that display content vertically or horizontally, without ratio distortion. Conveniently rotate your content with three display options: original ratio on a single screen, full ratio on a single screen, or full ratio on a video wall.

Present varied content with an optional PC module Present varied content with an optional PC module

Present varied content with an optional PC module

Present varied content with an optional PC module

Play content from a variety of sources with the optional Setback Box-C (SBB-C). Added to a UD55D display, the SBB-C shows specific business content and provides powerful PC functions to deliver on-target messages. To change the content displayed, you simply replace the SBB-C in individual displays or a control display. The control display then transmits the message to the other displays in the video wall. If you opt for an SBB-C in each display, you gain incredible flexibility in delivering multiple messages over your video wall.

Connect multiple displays without picture quality loss through DisplayPort 1.2 support

Join up to 100 displays without losing picture quality with the DisplayPort® (DP) 1.2 multistream support. By using DP 1.2, businesses can display content in ultra high definition (UHD) of 3,840 x 2,160 in 2 x 2 video walls without additional equipment. The High-bandwidth Digital Content Protection (HDCP) daisy-chain capability offered on UDC Series displays helps reduce the cost of deploying multiple displays. With the HDCP support, LiveTV®, Blu-ray Disc™ and other HDCP content can be presented without an HDCP distributor.

Magic Clone

Easily apply consistent settings to displays in multiple locations with Samsung Magic Clone, without the cumbersome efforts to set up displays one by one. Program one display for settings such as volume, brightness and more. After the first display has been updated, save the settings onto a USB or external drive. Then simply plug the USB or external drive into new displays to copy options from one display to others.

Specifications

Display

  • H-Scanning Frequency 30kHz - 81kHz
  • Maximum Pixel Frequency 148.5MHz
  • V-Scanning Frequency 48Hz - 75Hz

Panel

  • Diagonal Size 55"
  • Type D-LED DID
  • Resolution 1,920 x 1,080
  • Pixel Pitch(mm) 0.63mm (H) x 0.63mm (V)
  • Active Display Area 1,209.6 x 680.4mm
  • Brightness Max 700cd/m²
  • Contrast Ratio (Dynamic) 10,000:1
  • Viewing Angle (Horizontal/Vertical) 178/178
  • Response Time (G-to-G) 8ms
  • Display Color 8bit - 16.7M
  • Color Gamut 69%
  • Contrast Ratio 3,500:1

Connectivity

  • Input RGB Analog D-SUB, DVI-D, Display Port 1.2 Video HDMI1, HDMI2, Component(CVBS Common) Audio Stereo mini Jack
  • Output RGB DP1.2 (Loop-out) Audio Stereo mini Jack
  • External Control RS232C (in / out), RJ45
  • External Sensor Detachable type (IR, Ambient)

Mechanical Specification

  • Dimension Set Dimension (WxHxD) 1,213.5 x 684.3 x 96.0mm
  • Weight Set Weight 23.3kg
  • Media Player Option Type Embbeded, SBB-C (Slide In)

Operation

  • Operating Temperature 0°C - 40°C
  • Humidity 10 - 80%

General Feature

  • Key Ultra Narrow Bezel
  • Special ACM Support (Advanced Color Management), Magic Clone (to USB), Auto Source Switching & Recovery, Lamp Error Detection, Anti Retention (Haze 44%), Temperature Sensor, RS232C / RJ45 MDC,Plug and Play (DDC2B), PIP / PBP, Video Wall (10 x 10), Pivot Display, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain (Supporting 2 x 2 UHD Resolution, HDCP Support), Smart Scheduling, Smart F / W update, Clock Battery (80 hours Clock Keeping) Built In MagicInfo (Lite, Premium-S, Videowall-S)
  • Internal Player Processor Cortex-A9 1GHz Dual Core CPU On-Chip Cache Memory L1 (I / D): 32KB / 32KBL2 (Unified): 512KB Clock Speed 1GHz CPU Dual Main Memory Interface 1GBDual 32bit DDR3-667 (1,333MHz) Graphics 2D & 3D Graphics Engine - Up to 1,920 x 1,080. 32bpp - Supports OpenGL ES Storage (FDM) 8GB (2GB Occupied by O / S, 6GB Available) Multimedia Video Decoder - MPEG-1 / 2, H.264 / AVC (Dual) - VC-1, JPEG, PNG Audio DSP (Decoder) - AC3 (DD), MPEG, DTS and etc. IO Ports USB 2.0 Operating System Linux

Power

  • Power Supply AC 100 - 240V - (+ / - 10%), 50/60Hz
  • Power consumption Off Mode Less than 0.5 watt On Mode 209 (Max) / 175 (Typ.) / 713 (BTU) Sleep Mode Less than 0.5 watt
  • Type Internal

Embedded PC

  • CPU SBB-C (SIM Type)
  • N/B SBB-C (SIM Type)
  • S/B SBB-C (SIM Type)
  • GPU SBB-C (SIM Type)
  • FDM/HDD SBB-C (SIM Type)
  • Memory SBB-C (SIM Type)
  • Ethernet SBB-C (SIM Type)
  • Connectivity USB SBB-C (SIM Type) Output SBB-C (SIM Type) Others SBB-C (SIM Type)

certification

  • EMC FCC (USA) FCC Part 15, Subpart B class B CE (Europe) EN55022, EN55024 VCCI (Japan) V-3 (CISPR22) KCC (Korea):KN22, KN24 BSMI (Taiwan): CNS13438 (CISPR22) C-Tick (Australia): AS / NZS3548 (CISPR22) CCC (China): GB 9254-2008, GB 17625.1-2003
  • Environment ENERGY STAR 6.0 (USA)
  • Safety UL (USA): UL 60950-1 CSA (Canada): CSA C22.2 No. 60950-1 TUV (Germany): EN60950-1 NEMKO (Norway): EN60950-1 KC (Korea): K60950-1 CCC (China): GB 4943-2001 PSB (Singapore): IEC60950-1 GOST (Russia): IEC60950-1, EN55022 SIQ (Slovenia): IEC60950-1, EN55022 PCBC (Poland): IEC60590-1, EN55022 NOM (Mexico): NOM-019-SCFI-1993 IRAM (Argentina):IEC60950-1 SASO (Saudi Arabia): IEC60950-1

Accessory

  • Included Quick Setup Guide, Warranty Card,Application CD, DP cable, Power Cord, Remote Controller, Batteries,
