Client PCs

256 GB (1GB=1 Billionbyte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)

2.5 inch Form Factor

SATA 6Gb/s Interface, compatible with SATA 3Gb/s & SATA 1.5Gb/s interface

100 X 69.85 X 6.8 (mm) Dimension

Max 66.0g Weight

Samsung 3D V-NAND

Samsung 3-core MGX Controller

Samsung 512 MB Low Power DDR3 SDRAM cache memory

TRIM Supported

S.M.A.R.T Supported

Auto Garbage Collection Algorithm

AES 256 bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)

World Wide Name supported

Yes

Up to 550 MB/sec Sequential Read * Performance may vary based on system hardware & configuration

Up to 520 MB/sec Sequential Write * Performance may vary based on system hardware & configuration

Up to 100,000 IOPS Random Read * Performance may vary based on system hardware & configuration

Up to 90,000 IOPS Random Write * Performance may vary based on system hardware & configuration

Up to 10,000 IOPS Random Read * Performance may vary based on system hardware & configuration

Up to 36,000 IOPS Random Write * Performance may vary based on system hardware & configuration

*Average: 2.9 Watts *Maximum: 3.5 Watts (Burst mode)* Actual power consumption may vary depending on system hardware & configuration

0.03 Watts * Actual power consumption may vary depending on system hardware & configuration

5V ± 5% Allowable voltage

2 Million Hours Reliability (MTBF)

0 - 70 ℃ Operating Temperature

1,500G & 0.5ms (Half sine)

Not Available

Magician Software for SSD management

10 Years Limited Warranty(150TBW)
