EV-NX1100BABUS
Design
Color
Black Color

Color of the casing of the camera.


Black
Camera Type Smart Compact System Camera
In The Box
Included NX1100 20.3 SMART Camera (Black)
20-50mm F/3.5-5.6 ED Lens (Black)
SEF-8A Hot Shoe Mount Flash Unit
BP1030 Lithium-ion Battery
BC1030 Battery Charger & AC Cable
Body Cap
Camera Strap
Micro USB Cable
Image sensor
Effective Pixel
Effective Pixel: Approx. 20.3 Mega-pixels

Amount of pixels in a camera's chip that detect light and contribute to the final image.


Approx. 20.3 Mega-pixels
Total Pixel
Total Pixel: Approx. 21.6 Mega-pixels

Entire amount of pixels in a camera's chip regardless of whether any are shaded or inactive.


Approx. 21.6 Mega-pixels
Image Sensor Type CMOS
Lens
Type 20-50mm F/3.5-5.6 ED Lens (Black) EX-S2050BNB/US
Mount Samsung NX Mount
Included Lens EX-S2050BNB/US
Shutter Speed
Range
Modes Auto:1/4000sec. ~ 30sec.
Manual:1/4000sec. ~ 30sec. (1/3EV step)
Bulb ( Limit time : 4min. )
Exposure
ISO Equivalent
ISO Equivalent: Auto, 100, 200, 400, 800, 1600, 3200, 6400, 12800 (1 or 1/3EV step)
* AUTO ISO upper level is selectable. (Up to ISO3200)

Dictates how sensitive a camera's digital sensor is to light. Use higher ISO in darker conditions.


Auto, 100, 200, 400, 800, 1600, 3200, 6400, 12800 (1 or 1/3EV step)
* AUTO ISO Upper Level is Selectable. (Up to ISO3200)
Metering System
Metering System: TTL 221(17x13) Block Segment
Metering : Multi, Center-weighted, Spot
Metering Range : EV 0-18 (ISO 100 · 30mm, F2)

Set of modes that represent which aspect of the image will determine the exposure for a given shot.


TTL 221(17x13) Block Segment
Metering : Multi, Center-weighted, Spot
Metering Range : EV 0-18 (ISO 100 · 30mm, F2)
Focusing
Modes Single AF, Continuous AF, MF
Shooting
Modes SmartAuto(2.0), Program, Aperture Priority, Shutter Priority, Manual, Lens Priority, Magic, cene, Movie, Wi-Fi
RAW format shooting SRW
Display
Field of View
Field of View: Approx. 100%

Area of a given scene that is visible to the camera lens when taking a photo, as measured in centimeters.


Approx. 100%
Main LCD Screen 3" TFT LCD
Resolution 8VGA ( 640X40 ) 921k dots
Video
Movie Clip With Audio or without Audio (User Selectable, Recording Time : 25 minutes)
Flash
Modes Smart Flash, Auto, Auto+Red-eye reduction, Fill-in, Fill-in+Red-eye reduction, 1st Curtain, 2nd Curtain, OFF
Sync. Speed Less than 1/180 sec.
Range 28mm Wide-angle (Equivalent to 35mm)
Accessory Samsung External Flash Available (SEF-42A, SEF220A : Optional)
Image Stabilization
Optical Image Stabilization OIS Mode1 / Mode2 / OFF
Smart Settings
Smart Auto 2.0
Smart Filter (Movie) Vignetting, Miniature, Fish-Eye, Sketch, De-fog, Halftone Dots, Soft Focus,Old Film1, Old Film2, Negative
Smart Filter (Still Image) Miniature, Soft Focus, Old Film1, Old Film2,, Halftone Dots, Sketch, Fish-Eye, De-fog Negative
Picture Effects
Picture Wizard Modes:
Standard, Vivid, Portrait, Landscape, Forest, Retro, Cool, Calm, Classic, Custom (1~3)
Parameters:
Contrast, Sharpness, Saturation, Color
i-Function
i-Effect i-Scene (depends on Lens)
Smart Filter (Vignetting, Minature, Fish-Eye, Sketch, Defog, Halftone Dot)
i-Zoom x1.2, 1.4, 1.7, 2.0
Dust Reduction
Dust Reduction Type: Supersonic drive
White Balance
Modes Auto, Daylight, Cloudy, Fluorescent (W, N, D), Tungsten, Flash, Custom, K(Manual)
Storage
File Format
RAW (SRW), JPEG (EXIF 2.21), DCF, DPOF 1.1, PictBridge 1.0

How images and data are stored when uploaded to a computer or printed directly from camera.


RAW (SRW), JPEG (EXIF 2.21), DCF, DPOF 1.1, PictBridge 1.0
Image Size 20.0M RAW 53
20.0M (3:2) : Super Fine 186, Fine 364, Normal 535
10.1M (3:2) : Super Fine 378, Fine 724, Normal 1043
5.9M (3:2) : Super Fine 626, Fine 1168, Normal 1642
2.0M (3:2) : Super Fine 1627, Fine 2742, Normal 3553
Burst (5.0M) : Super Fine 731, Fine 1349, Normal 1878
7.8M (16:9) : Super Fine 485, Fine 919, Normal 1310
4.9M (16:9) : Super Fine 747, Fine 1376, Normal 1912
2.1M (16:9) : Super Fine 1573, Fine 2666, Normal 3468
13.3M (1:1) : Super Fine 289, Fine 560, Normal 814
7.0M (1:1) : Super Fine 536, Fine 1010, Normal 1432
4.0M (1:1) : Super Fine 893, Fine 1621, Normal 2224
1.1M (1:1) : Super Fine 2645, Fine 4057, Normal 4936
Wireless Connectivity
WiFi Yes (IEEE 802.11n support)
Inputs & Outputs
USB 2.0 USB 2.0 (HI-SPEED)
Video Out NTSC, PAL (user selectable)
HDMI 1.4a : (1080i, 720P, 576P / 480P)
Dimensions
Product Size (WxHxD) 4.59" x 2.46" x 1.44"
Weight
Product without battery and card 0.48 lb.
Power
Power Source Rechargeable Battery
Battery BP1030 (1030mAh)
System Requirements
Windows PC with processor better than Intel Pentium III 500MHz
(Intel Pentium 800MHz or higher recommended)
Windows XP / Vista / 7
Minimum 256MB RAM (512MB or more recommended)
250MB of available hard disk space (1GB or more recommended)
USB port,CD-ROM drive
1024x768 pixels, 16-bit color display compatible monitor (24-bit color display recommended)
Microsoft Direct X 9.0c or later
intelli-studio 3.0
Windows XP SP2 / Vista / 7
Intel Core 2 Duo 1.66 GHz or higher / AMD AthlonTM X2 Dual-Core 2.2 GHz or higher
Minimum 512MB RAM (1GB or more recommended)
250MB of available hard disk space (1GB or more recommended)
1024x768 pixels, 16-bit color display compatible monitor
(1280x1024 pixcels, 32-bit color display recommended)
USB 2.0, Microsoft DirectX 9.0c or later
nVIDIA Geforce 7600GT or higher / ATI X1600 series or higher
# 64-bit editions of Windows XP / Vista / and 7 are not supported
Samsung RAW converter 4
Windows XP / Vista / 7
Intel Pentium, AMD Athlon Processor
(Intel Pentium 4, AMD Athlon XP or later recommended)
1GB or more RAM recommended
Minimum 100MB of available hard disk space
1024x768 pixels, Full Color (24-bit or higher) color display compatible monitor
Macintosh Power Mac G3 or later
Mac OS 10.4 or later
Minimum 256MB RAM (512MB or more recommended)
Minimum 110MB of available hard-disk space
USB port,CD-ROM drive
Samsung RAW converter 4
Mac OS X v10.6 / v10.5 / v10.4
Power PC / Intel Processor-based or compatible computer (Core 2 Quad or later recommended)
1GB or more RAM recommended
Minimum 100MB of available hard disk space
1024x768 pixels, 24-bit color display compatible monitor
Operating Conditions
Humidity
Humidity: 5 ~ 85%

Minimum and maximum air moisture in which a camera will operate, as measured in percentage.


5 ~ 85%
Temperature
Temperature: 0 ~ 40 °C

Climate range in which a camera can operate, as measured in Celsius degrees. 0-40 C = 32-104 F.


0 ~ 40 °C
Software
Included in Box Adobe Lightroom Software CD
