970 EVO Plus NVMe ™ M.2 SSD 2TB

Name: 970 EVO Plus NVMe ™ M.2 SSD 2TB
Brand: Samsung
SKU: MZ-V7S2T0BW
Rating: 4.9 (12 reviews)

2 TB

MZ-V7S2T0BW

Not for sale

+3 more

970 EVO Plus NVMe ™ M.2 SSD 2TB

Dimension

Spin the angle

Features

Always Evolving SSD

The ultimate in performance, upgraded. Faster than the 970 EVO, the 970 EVO Plus is powered by the latest V-NAND technology and firmware optimisation. It maximises the potential of NVMe™ bandwidth for unbeatable computing in capacities up to 2TB, with reliability of up to 1,200 TBW.

*1GB=1,000,000,000 bytes by IDEMA. A certain portion of capacity may be used for system file and maintenance use, so the actual capacity may differ from what is indicated on the product label.

Level Up Performance

The 970 EVO Plus reaches sequential read/write speeds up to 3,500/3,300 MB/s, up to 53%‡ faster than the 970 EVO. The latest V-NAND—which brings greater NAND performance and higher power efficiency—along with optimised firmware, a proven in-house controller and Intelligent TurboWrite boost.

* Sequential and random write performance was measured with Intelligent TurboWrite technology being activated. Intelligent TurboWrite operates only within a specific data transfer size. Performance may vary depending on SSD’s firmware, system hardware & configuration and other factors. For detailed information, please contact your local service centre.

Design Flexibility

The next advancement in NVMe SSD. The 970 EVO Plus fits up to 2TB onto the compact M.2 (2280) form factor, greatly expanding storage capacity and saving space for other components. Samsung’s innovative technology empowers you with the capacity to do more and accomplish more.

Exceptional Endurance

The new standard in sustainable performance. Get up to 1,200 TBW with a 5-year limited warranty for lasting performance. The 970 EVO Plus provides exceptional endurance powered by the latest V-NAND technology and Samsung’s quality.

* TBW: Terabytes Written * Warrantied TBW for 970 EVO Plus: 150 TBW for 250GB model, 300 TBW for 500GB model, 600 TBW for 1TB model, 1,200 TBW for 2TB model. * 5-years or TBW, whichever comes first. For more information on the warranty, please find the enclosed warranty statement in the package.

Unparalleled Reliability

Achieve a new level of drive confidence. Samsung’s advanced nickel-coated controller and heat spreader on the 970 EVO Plus enable superior heat dissipation. The Dynamic Thermal Guard automatically monitors and maintains optimal operating temperatures to minimise performance drops.

Samsung Magician

Advanced drive management made simple. The Samsung Magician software will help you keep an eye on your drive. A suite of user-friendly tools helps keep your drive up to date, monitor drive health, check speed and even boost performance.

Specifications

Application

Client PCs
Interface

PCIe Gen 3.0 x4, NVMe 1.3
Dimension (WxHxD)

80.15 x 22.15 x 2.38 (mm)
Weight

Max 8.0 g Weight
Performance

Up to 3,500 MB/s * Performance may vary based on system hardware & configuration
Sequential Write

Up to 3,300 MB/s * Performance may vary based on system hardware & configuration
Warranty

5-Year Limited Warrantyor 1,200 TBW Limited Warranty

Application

Client PCs
Capacity

2,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor

M.2 (2280)
Interface

PCIe Gen 3.0 x4, NVMe 1.3
Dimension (WxHxD)

80.15 x 22.15 x 2.38 (mm)
Weight

Max 8.0 g Weight
Storage Memory

Samsung V-NAND 3-bit MLC
Controller

Samsung in-house controller
Cache Memory

Samsung 2GB Low Power DDR4 SDRAM

TRIM Support

Supported
S.M.A.R.T Support

Supported
GC (Garbage Collection)

Auto Garbage Collection Algorithm
Encryption Support

AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support

Not supported
Device Sleep Mode Support

Yes

Sequential Read

Up to 3,500 MB/s * Performance may vary based on system hardware & configuration
Sequential Write

Up to 3,300 MB/s * Performance may vary based on system hardware & configuration
Random Read (4KB, QD32)

Up to 620,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD32)

Up to 560,000 IOPS * Performance may vary based on system hardware & configuration
Random Read (4KB, QD1)

Up to 19,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD1)

Up to 62,000 IOPS * Performance may vary based on system hardware & configuration

Average Power Consumption (system level)

*Average: 6 W*Maximum: 9 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle)

Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage

3.3 V ± 5 % Allowable voltage
Reliability (MTBF)

1.5 Million Hours Reliability (MTBF)
Operating Temperature

0 - 70 ℃ Operating Temperature
Shock

1,500 G & 0.5 ms (Half sine)

Installation Kit

Not Available

Management SW

Magician Software for SSD management

5-Year Limited Warrantyor 1,200 TBW Limited Warranty
