990 EVO Plus, PCIe 4.0/5.0, NVMe M.2 SSD

Name: 990 EVO Plus, PCIe 4.0/5.0, NVMe M.2 SSD
Brand: Samsung
SKU: MZ-V9S1T0BW

Black 1 TB

MZ-V9S1T0BW

Not for sale

+3 more

990 EVO Plus, PCIe 4.0/5.0, NVMe M.2 SSD

Dimension

Spin the angle

Features

Upgrade everyday performance

Top 3 features

The phrase "Up to 7,250 MB/s" is written on a rectangle shaped like the 990 EVO Plus.

Performance

Up to 7,250MB/s of sequential read speed, 45% faster speed than the previous model, the 990 EVO.

It says "73% Enhanced" on the dashboard.

Power efficiency

Power efficiency enhanced by 73% compared to the 990 EVO for more MB/s per watt, while maintaining performance and thermal control.

It says "Up to 4TB" inside two connected circles.

Versatility

Up to 4TB capacity and rapid Intelligent TurboWrite 2.0.

Spectacular speed everyday

Blast through tasks faster. 990 EVO Plus with the latest NAND offers boosted sequential read/write speeds up to 7,250/6,300MB/s. Huge files, instant transfer.

* Sequential and random write performance was measured with Intelligent Turbo Write technology being activated. Intelligent Turbo Write operates only within a specific data transfer size. Performance may vary depending on SSD’s firmware, system hardware & configuration and other factors. For detailed information, please contact your local service center.* Test system configuration: AMD Ryzen9 7950x 16-Core Processor CPU@4.5GHz, DDR5 4800MHz 16GBx2 (PC5-38400), OS-Windows 11 Pro 64bit, Chipset - ASRock X670E Taichi* To maximize the performance of the 990 EVO Plus, please check whether your system supports PCIe® 4.0 or PCIe® 5.0 at the Intel or AMD website.* Product image shown for illustrative purposes only; actual product may differ.

Keep cool and power through your day

Optimised efficiency, extended performance. The nickel-coated controller increases MB/s per Watt by 73% compared to the 990 EVO, achieving the same power level and thermal control with less power consumption. Stay focused on work or play without worrying about overheating or battery life.

Extra space. Extra speed.

Harness the full power of your drive with enhanced Intelligent TurboWrite 2.0. Process massive data faster and breeze through heavy graphics with an enlarged TurboWrite region, now available in 4TB capacity.

*Compared to the previous model, the 990 EVO

Samsung Magician software

Make your SSD work like magic. Samsung Magician software's optimisation tools ensure the best SSD performance. It's a safe and easy way to migrate all your data for a Samsung SSD upgrade. Protect valuable data, monitor drive health, and get the latest firmware updates.

* For detailed information, please visit Samsung Magician software website.https://semiconductor.samsung.com/consumer-storage/magician/

Bringing innovations to life

For decades, Samsung’s NAND flash memory has powered groundbreaking technologies that have changed every part of our daily lives. This NAND flash technology also powers our consumer SSDs, making room for the next big push of innovation.

Specifications

Interface

PCIe® 4.0 x4 / 5.0 x2 NVMe™ 2.0
Sequential Read

Up to 7,150 MB/s * Performance may vary based on system hardware & configuration
Sequential Write

Up to 6,300 MB/s * Performance may vary based on system hardware & configuration
Warranty

5-year Limited Warranty or 600TBW Limited Warranty
Application

Client PCs
Weight

Max 9.0g Weight
Dimension (WxHxD)

Max 80.15 x Max 22.15 x Max 2.38 mm

Application

Client PCs
Capacity

1,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor

M.2 (2280)
Interface

PCIe® 4.0 x4 / 5.0 x2 NVMe™ 2.0
Dimension (WxHxD)

Max 80.15 x Max 22.15 x Max 2.38 mm
Weight

Max 9.0g Weight
Storage Memory

Samsung V-NAND TLC
Controller

Samsung in-house Controller
Cache Memory

HMB(Host Memory Buffer)

TRIM Support

Supported
S.M.A.R.T Support

Supported
GC (Garbage Collection)

Auto Garbage Collection Algorithm
Encryption Support

AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support

Not supported
Device Sleep Mode Support

Yes

Sequential Read

Up to 7,150 MB/s * Performance may vary based on system hardware & configuration
Sequential Write

Up to 6,300 MB/s * Performance may vary based on system hardware & configuration
Random Read (4KB, QD32)

Up to 850,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD32)

Up to 1,350,000 IOPS * Performance may vary based on system hardware & configuration

Average Power Consumption (system level)

Average: Read 4.3 W / Write 4.2 W* Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle)

Typical 60 mW * Actual power consumption may vary depending on system hardware & configuration
Power Consumption (Device Sleep)

Typical 5 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage

3.3 V ± 5 % Allowable voltage
Reliability (MTBF)

1.5 Million Hours Reliability (MTBF)
Operating Temperature

0 - 70 ℃ Operating Temperature
Shock

1,500 G & 0.5 ms (Half sine)

Installation Kit

Not Available

Management SW

Magician Software for SSD management

5-year Limited Warranty or 600TBW Limited Warranty
