Specs
QBH-TR Series Digital Signage (QB65H-TR)
Specification
QBH-TR Series Digital Signage (QB65H-TR)
Series Name
QB65H-TR
Display
65"
60Hz E-LED
3840x2160
300nit (w/o Touch Glass)
Mega
178:178
8ms
16/7
Connectivity
VIDEO: HDMI Rear1, HDMI Rear2 (ver 2.0), HDMI Front3 (ver 1.4), DVI-D, DP
USB: USB 1, 2 (Rear), USB 3 (Front), PC USB (Front)
AUDIO: AUDIO
TOUCH: Touch Out 1 (Rear), Touch Out 2 (Front)
RS232C(in/out) thru stereo jack, RJ45, Wi-Fi
IR Sensor(Display Control)
Power
AC 100~240V 50/60Hz
115(Typical), 150(Rating)
less than 0.5W
Environmental Conditions
0℃~ 40℃
10~80%
Features
Slim & Light LFD with Built-in MagicInfo Player S5, SSSP
HARDWARE: Super Clear Coating, Temperature Sensor, Clock Battery (168hrs Clock Keeping), Built in Speaker(10W x 2), WiFi Module Embedded
SOFTWARE: MagicIWB S5
Yes
Yes
Built in Speaker (10W x 2)
(Down Firing w/Bass Reflex)
Touch
IR
4 drawing (SoC), 10 drawing (External Windows PC)
Passive Pen
8mm
7ms
Internal Player
Coretex A72 1.7GHz Quad-Core CPU
L1 Instruction Cache : 48KB
L1 Data Cache : 32KB
L2 Cache : 2MB
1.7GHz Quad-Core CPU
3GB
3ch 64bit LPDDR4 1.6GHz
2D & 3D Graphic Accelerator
Data Format : 32bpp
Output resolution : 3840x2160p
8GB
(3.88GB Occupied by O/S, 4.12GB Available)
Video Decoder
- MPEG 1/2/4, H.263, H.264/AVC
- UHD H.264/AVC, VC-1, AVS/AVS+, MVC
- VP8, VP9, HEVC, JPEG
Audio DSP(Decoder)
- MPEG, AC3, AC4, DD, MP3 and etc
USB 2.0
Tizen 3.0 (VDLinux)
Dimensions
1514.7 X 882.4 X 58.2 mm
1619 X 231 X 1001 mm
Weight
39.2 kg
48.0 kg
Accessories
Passive Pen, Power Cable
WMN6575SE
Mechanical Specs
400 x 400
Black
Yes
Wall Mount
1.8m
Pen Holder
