SC370 Series (S24C370HL)
Product info
Manual, downloads, specs and register
SC370 Series (S24C370HL) edit- SC370 Series
- 390 Series
- Model
- C27F390FHN
- SA300 Series
- Model
- S20A300B
- SA350 Series
- Model
- S23A350H
- S27A350H
- SB300 Series
- Model
- S23B300H
- S24B300EL
- SB350 Series
- Model
- S20B350H
- S22B350T
- S23B350H
- S23B350T
- S24B350H
- S24B350TL
- SB370 Series
- Model
- S27B370H
- SC300 Series
- Model
- S20C300BL
- S22C300H
- S24C300HL
- SC310 Series
- Model
- S24C310HL
- SC350 Series
- Model
- S23C350H
- S24C350H
- S27C350H
- S22C350H
- SC370 Series
- Model
- S24C370HL
- 330 Series
- Model
- S24D330H
- 310 Series
- Model
- S22E310H
- S31A Series
- Model
- S24A310NHN
- T37F Series
- Model
- F24T374FWN
- F22T374FWN
- CF396 Series
- Model
- C24F396FHN
- CF398 Series
- Model
- C27F398FWN
- SF354 Series
- Model
- S24F354FHN
- T35F Series
- Model
- F24T350FHN
- SR350 Series
- Model
- S22R350FHN
- SR356 Series
- Model
- S24R356FHN
- S27R356FHN
- S33A Series
- Model
- S22A330NHN
- S24A336NHN
- S22A338NHN
- S24A338NHN
- FT350 Series
- FT350 Series
- Model
- F22T350FHN
- F27T350FHN
- F24T350FHN
- S30B Series
- Model
- S32B300NWN
- S32B304NWN
- 300 Series
- Model
- S27C392EAN
- S32C392EAN
- S43GC Series
- Model
- S24C332GAN
- S27C432GAN
- [SELECT]
Register
Gain access to exclusive offers and perks, apps and services, world-class customer support and more.
register nowManuals
JAN 20,2014
User Manual
ver. 1.0, SPANISH
4.89 MB
JAN 20,2014
User Manual
ver. 1.0, ENGLISH
4.87 MB
JAN 20,2014
User Manual
ver. 1.0, KOREAN
5.13 MB
Downloads
MAR 21,2013
Device(Install)
ver. 1.0 Win 2000/XP/Vista/Win7/Win8 (32,64bit) MULTI LANGUAGE
- Title Monitor Driver
- Applicable Model S24C370HL
- Carrier or Corporate Customer Open Market
- Description If you have trouble for setting up the Monitor under Windows 2000/XP/Vista/7 this program will help you to install Windows Monitor Driver. You can install the most suitable Windows driver for your monitor.System Requirements : Windows 2000/ XP/ Vista/ 7/ 8(32bit/64bit)
8.02 MB
Specs
SC370 Series (S24C370HL)
SEE FULL SPECS
Specification
SC370 Series (S24C370HL)
Display
Model Number
S24C370HL
Screen Size
The diagonal measurement of a TV screen or monitor, from corner to corner.
23.6"
Display Type
The type of monitor panel technology (typical listings include TN, VA, IPS, PLS)
LED TN
Resolution
Fixed number of horizontal scan lines on a monitor. P (Progressive) means scan lines are drawn in sequence.
1920 x 1080
Aspect Ratio
Ratio of the width of an display to its height. 16:9 is the universal standard for high-definition display.
16:9
Brightness
250cd/m2
Static Contrast Ratio
Difference in light intensity between brightest color (white) & darkest (black). Higher ratio means more contrast.
1000:1
Dynamic Contrast Ratio
Difference in luminosity between brightest color (white) & darkest (black) over time. Higher ratio means more contrast.
Mega ∞ DCR
Viewing Angle (Horizontal/Vertical)
Degrees from side to side (and above to below) from which a screen can be viewed without loss of quality.
170°/160°
Response Time
Typical speed at which pixels can change color. Lower response times mean better motion image reproduction.
5ms
Color Support
Number of colors that an LCD monitor is capable of displaying.
16.7M
Power
Type
External Adaptor
Power Supply Type
AC100-240V (50/60Hz)
Power Consumption (Max)
20 W
Power Consumption (Stand-by)
0.3 W
Max Stand By Power (DPMS)
Energy consumed by a monitor while off or in sleep mode, as per Display Power Management Signaling.
0.3 W
Features
Special
Eco Saving
Magic Upscale
Multi Screen S/W
Samsung MagicBright3
Off Timer
MagicTune
Image Size
Magic Angle
VGA
Yes
HDMI
High-Definition Multimedia Interface. The industry standard for transmitting HD video for display.
Yes
Stand
Simple Tilt
Mac Compatible
Yes
Windows Compatible
Yes
Dimensions (W x H x D)
Product Dimensions With Stand
Width, height and depth of the monitor, including stand, as measured in inches (in.).
22.18" x 17.45" x 9.06"
Product Dimensions Without Stand
Width, height and depth of the monitor, without stand, as measured in inches (in.).
22.18" x 17.35" x 4.31"
Shipping Dimensions
Width, height and depth of the monitor, including shipping container, as measured in inches (in.).
25.07" x 20.03" x 6.41
Weight (lb.)
Product Weight With Stand
Weight of the monitor, as measured in pounds (lb.).
8.58 lb.
Product Weight Without Stand
Weight of the television, without stand, as measured in pounds (lb.).
7.81 lb.
Shipping Weight
Weight of the monitor, including shipping container, as measured in pounds (lb.).
12.10 lb.
Accessories
Installation Software
Install CD (Manual), Quick Setup Guide
VGA Cable
Included
Power Cable
Included
Green Management
ENERGY STAR® Certified
Approval by Energy Star, a government program, ensures TV is eco-friendly and energy efficient.
Yes
Inputs
VGA
Video Graphics Array. Port that transmits analog component video signals by way of 15 shielded pins.
1
HDMI
High-Definition Multimedia Interface. The industry standard for transmitting HD video for display.
1
Outputs
Optical Audio Out
Terminal used to transmit digital audio streams between components without interference.
Audio Out
