MZ-750500BW

SSD 750 EVO 2.5” SATA III 500GB

4.6 OUT OF 5 STARS (18)

Cost-effective SSD featuring TurboWrite and RAPID mode for ultrafast computing

NAND flash-based, lightweight, and shock and vibration resistant

2.5" SATA III

Form Factor

Turbo Write Technology

Turbo Write Technology

540MB/s Seq. Read

540MB/s Seq. Read

520MB/s Seq. Write

520MB/s Seq. Write

Incredible Read/Write Speeds

The Samsung 750 EVO 500GB boasts fast random read/write performance, so you can boost computing productivity.

Incredible Read/Write Speeds
TurboWrite Technology and RAPID mode

TurboWrite Technology and RAPID mode

TurboWrite technology dramatically boosts the sequential read/write (R/W) speeds up to 540/520 MB/s. RAPID mode provides the option to heighten performance on demand by using free PC memory (DRAM) as a cache, enabling ultrafast multitasking for improved operational efficiency and productivity.

Guaranteed Endurance and Reliability

With no moving parts, the NAND flash-based 750 EVO is durable and lightweight, making it the ideal choice for working on the go. It is also shock and vibration resistant for worry-free operation. With a 3-year warranty up to 100 TBW (Terabytes Written) and 1.5 million hours Mean Time Between Failures (MTBF), your investment is secured.

Guaranteed Endurance and Reliability
Secure Data Through Advanced AES 256 Encryption

Secure Data Through Advanced AES 256 Encryption

You can trust the 750 EVO to keep your data safe with Samsung SED (Self-Encrypting Drive) technology. An AES 256-bit hardware-based full disk encryption engine secures data while maintaining high performance.

End-to-end Integration Solution

The 2.5" form factor and 7 mm height of the 750 EVO is optimized to upgrade desktops and slim laptops, and includes software for simple installation and management. Samsung Data Migration software features robust custom cloning that ensures seamless migration, even if the source data is greater than the capacity of the SSD.

End-to-end Integration Solution
One-stop Install Navigator Software

One-stop Install Navigator Software

Samsung Magician software simplifies SSD management, enabling you to maximize both the performance and the lifespan of the SSD. It also facilitates data security features, including Secure Erase.

Features and specifications are subject to change without prior notification

2.5" SATA III
Form Factor
Turbo Write Technology
Turbo Write Technology
540MB/s Seq. Read
540MB/s Seq. Read
520MB/s Seq. Write
520MB/s Seq. Write
Secure Encryption
Secure Encryption
3-yr Limited Warranty
3-yr Limited Warranty
  • Type

    Product Type

    Solid State Drive

    Series

    750 EVO

    Interface

    SATA 6Gb/s Interface, compatible with SATA 3Gb/s & SATA 1.5Gb/s interface

  • Application

    Consumer

    Client PCs

  • Storage

    Capacity

    500GB* * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)

  • Key Features

    Sequential Read Speed

    Up to 540 MB/s Sequential Read* * Performance may vary based on system hardware & configuration

    Sequential Write Speed

    Up to 520 MB/s Sequential Write* * Performance may vary based on system hardware & configuration

    Random Read Speed

    Random Read (4KB, QD32): Up to 98,000 IOPS Random Read* * Performance may vary based on system hardware & configuration Random Read (4KB, QD1): Up to 10,000 IOPS Random Read* * Performance may vary based on system hardware & configuration

    Random Write Speed

    Random Write (4KB, QD32): Up to 88,000 IOPS Random Write* * Performance may vary based on system hardware & configuration Random Write (4KB, QD1): Up to 40,000 IOPS Random Write* * Performance may vary based on system hardware & configuration

    Memory Speed

    Samsung Nand Flash Memory Samsung 512MB LPDDR3

    Controller

    Samsung MGX controller

    NAND Flash

    Samsung Nand Flash Memory

    Trim Support

    Yes (Requires OS Support)

    AES Encryption

    AES 256 bit Full Disk Encryption (FDE), TCG/Opal v2.0, IEEE1667 (Encrypted drive)

    S.M.A.R.T. Support

    Yes

    GC (Garbage Collection)

    Yes

    Internal Storage

    Yes

    Temperature proof

    Yes

  • General

    Power Consumption (W)

    Active Read/Write (Average): 2.3W / 2.5W* * Actual power consumption may vary depending on system hardware & configuration

    Reliability (MTBF)

    1.5 million hrs Reliability (MTBF)

  • Environmental Specs

    Operating Temperature

    32 - 158

    Operating Humidity

    5% to 95%, non-condensing

    Shock

    Non-Operating: 1500G, duration 0.5m sec, 3 axis

  • Form Factor

    Product

    2.5" SATA III

  • Dimensions (W x D x H)

    Product

    3.94" x 2.75" x 0.27"

  • Weight

    Product

    1.6

  • Warranty

    Product

    3 Years Limited Warranty or 100 TBW Limited Warranty
