BrilliantVIEW Baby Monitoring System



About This Product

The Samsung BrilliantVIEW monitoring system delivers crisp and clear videos in a large 4.3" LCD color monitor. With the remote pan, tilt, and zoom camera, you can control the camera to see if the baby is really asleep, keep track of others in the room or check if the door is closed.

Ultra-Large 4.3" LCD Monitor

The slim, compact wireless monitor with an ultra-large 4.3" LCD color screen delivers high resolution (VGA 640 x 480) brilliance in color and clarity for a clean, crisp picture.

Pan, Tilt & Zoom (PTZ)

The parent monitor features simple controls that direct the camera to zoom in and out, pan to 300⁰ left and right, or tilt 110⁰ up or down. In the nursery, PTZ lets you point the camera to know if the covers get kicked off, see if the door is closed or keep track of others in the room.

Pure Digital Signal

The Pure Digital Signal utilizes 2.4 GHz frequency to provide secure and interference-free video uninterrupted by wireless routers, microwaves, or cordless phones. Within a range of 900 feet*, you can do what you need to without losing contact with your little one.
* Range depends on obstacles between camera and monitor.

Two-Way Talk

The monitor goes beyond just listening. Its built-in mic lets you coo back, sing a lullaby or tell your little wonder you’re close by or on your way. Its Sound Level Indicator LED lights assure you’ll know when baby needs attention even when you’re in a noisy room.

Night Vision

The camera has night vision capability up to 15 feet, using infrared LED lights, so you can keep an eye on your baby even in low-light conditions. The camera's sensors detect light levels and adjust the image for optimal picture.


When nighttime is just a little too dark for your baby’s peace of mind, use your parent monitor to remotely activate the soft, calming night-light if the room needs a little glow.

Easy Set-up & Operation

With the camera recording on A/C power and the monitor using a built-in rechargeable battery, just charge the monitor to start enjoying your "favorite view." The monitor's parent-friendly interface makes customizing and navigating through the options a snap.

Quiet Mode

The voice activated (VOX) Quiet Mode reduces white ambient noise that comes through the monitor. Set the sound sensitivity level to be alerted to only those sounds that really matter.

Sleep Mode

Press the Sleep button to turn off the monitor screen and save battery power. The monitor will continue to detect sound around the camera even when the screen is off.


The monitor supports up to four cameras, extending your watchful eye to more than one child, or others in the house, and four separate living areas.

Features and specifications are subject to change without prior notification


  • Transmitting Power

    17dBm Max

  • Type of Spread Spectrum

    FHSS 15 channels

  • Total Pixel

    640 x 480 (VGA)

  • Display

    Color 4.3" LCD

  • Resoultion

    480 x 272

Full Specifications


  • Operating Frequency

    2.4 GHz

  • Transmitting Power

    17dBm Max

  • Receiving Sensitivity


  • Type of Spread Spectrum

    FHSS 15 channels

  • Type of Modulation


  • Date Rate


  • Transmitting Distance

    300m * Range depends on obstacles between the camera and the monitor

  • Operating Temperature (F)
    Climate range in which a projector will operate, as measured in Celsius degrees. 5-35 C = 41-95 F.


  • Humidity
    Minimum and maximum air moisture in which a camera will operate, as measured in percentage.

    Less Than 85%


  • Imaging Device

    1/5" CMOS

  • Total Pixel

    640 x 480 (VGA)

  • Video Compression Format


  • White Balance


  • Lens Focal Length


  • Max Aperture Ratio


  • Angular Field of View


  • Min. lllumination

    2 Lux without IR

  • IR

    940nm, 5m

  • Speaker Out


  • Power Consumption

    480mA (without IR LED)

  • Special Features

    Night vision

LCD Monitor

  • Display

    Color 4.3" LCD

  • Resoultion

    480 x 272

  • Number of Camera Support

    up to 4 cameras

  • Speaker Output


  • Power Consumption

    Max. 480mA (maximum condition charging + speaker with voice at volume 5)

  • Battery

    1300mA, Li-on, 4 hrs

  • Digital Zoom
    Range of magnification a camera can generate, as measured in degrees exponential to the original.


  • Special Feature(s)

    Auto scan/Stand by/VOX/Two way talk/Time display
