Using Flex Mode on Your Electric Wall Oven (NV51K7770S)

Flex mode lets you use different settings for the upper and lower compartments, such as different switch off times, cooking modes, cooking times, and temperatures settings. To apply or modify settings in either compartment, touch the respective touch pad.

Using the Flex Mode

  1. To use Flex mode, insert the divider (Flex Duo).





  2. To select the compartment you want to use, touch FLEX UPPER or FLEX LOWER. For this example, touch FLEX UPPER.





  3. Turn the Mode knob to the desired cooking operation.





  4. Set the desired temperature. Then, touch START.





  5. To set a cooking operation for Flex Lower, touch FLEX LOWER.





  6. Set the desired cooking operation and temperature. Then, touch START.





Flex Mode Temperature Setting Ranges



Flex Upper compartment

FLEX LOWER COMPARTMENT

(Available function setting and temperature)

Mode Set Temp. Bake, Convection Bake
MIN MAX
Broil HI 400°F 480°F
Low 325°F 480°F
Convection Bake &
Convection Roast
480°F 400°F 480°F
450°F 350°F 480°F
300°F 250°F 375°F
250°F 225°F 300°F
175°F 175°F 200°F



Oven temperatures in the flex lower compartment also limit broil settings in the flex upper compartment.



Flex lower compartment

FLEX UPPER COMPARTMENT

(Available function settings and temperature)

Mode Set Temp. Broil Convection Bake & Roast
LOW HI MIN MAX
Convection Bake &
Convection Roast
480°F O O 400°F 480°F
450°F O O 350°F 480°F
350°F O X 275°F 450°F
325°F O X 275°F 400°F
250°F X X 225°F 300°F
175°F X X 175°F 200°F

Oven Functions

Oven Oven functions

Without divider
Single Bake, Broil, Convection Bake, Convection Roast, Steam Bake, Steam Roast, Keep Warm, Healthy Cook, Gourmet Cook, Smart Control, Clean
With divider Twin  Upper Broil, Convection Bake, Convection Roast, Steam Bake, Healthy Cook
Lower Bake, convection Bake, Healthy Cook
