Features

Specifications

  • Cooling (Min / Std / Max)

    12.1 kW

  • EER (Std, Cooling), EER

    4.5

  • Unit Dimension (WxHxD)

    940 x 1210 x 330 mm

  • Type

    DVM S Eco HR

  • Outdoor Unit

    AM040NXMDER/EU

  • 1,2, 220-240, 50

  • Mode

    HR

  • 4 HP

  • Cooling (Min / Std / Max)

    12.1 kW

  • Heating (Min / Std / Max)

    12.1 kW

  • Cooling 1)

    2.69 kW

  • Heating 2)

    2.52 kW

  • Cooling 1)

    12.3 A

  • Heating 2)

    11.5 A

  • MCA

    22.0 A

  • MFA

    25.0 A

  • EER (Std, Cooling), EER

    4.5

  • COP (Std, Heating), COP

    4.8

  • Type

    Twin BLDC Rotary

  • Output(kW)

    4.04 kW

  • Model

    UG5TK5450FJX x 1

  • Oil (Type)

    PVE

  • Oil (Initial Charge) [cc]

    1700 cc

  • Type

    Propeller

  • Motor (Output) [W]

    125 W

  • Number of Unit (EA)

    2 EA

  • Air Flow Rate [m3/h]

    6000 ㎥/h

  • Liquid Pipe (Φ, mm)

    9.52 mm

  • Liquid Pipe (Φ, inch)

    3/8"

  • Gas Pipe (Φ, mm)

    15.88 mm

  • Gas Pipe (Φ, inch)

    5/8"

  • Max. Allowable Piping Length [m]

    150 m

  • Max. Allowable Piping Height [m]

    50 m

  • Type

    R410A(Contains fluorinated greenhouse gas, GWP=2,088)

  • Factory Charging (kg)

    3.20 kg

  • Factory Charging (tCO2e)

    6.68 tCO2e

  • Sound Pressure

    50 dBA

  • Sound Power

    68 dBA

  • Net Weight (kg)

    97.0 kg

  • Shipping Weight (kg)

    107.0 kg

  • Unit Dimension (WxHxD)

    940 x 1210 x 330 mm

  • Shipping Dimension (WxHxD)

    995 x 1388 x 426 mm

  • Cooling (℃)

    -5.0 ~ 48.0 ℃

  • Heating (℃)

    -25.0 ~ 26.0 ℃
