990 EVO, PCIe 4.0/5.0, NVMe M.2 SSD

Features
Gallery
Specs
Reviews
Support
Compare

Upgrade everyday performance

Top 3 features

The phrase "Up to 5,000 MB/s" is written on a rectangle shaped like the 990EVO.

Performance

Upgrade to faster sequential read speed up to 5,000 MB/s, reaching 43% faster than the previous model.

The phrase "70% Enhanced" is written within the overlapping lines that draw a circle.

Power efficiency

70% enhanced power efficiency compared to the previous model, supporting Modern Standby and longer battery life.

The words "Game, Work, Create" are written on a gaming mouse, circular graph, and tablet device.

Versatility

Elevate everyday performance in gaming, business, and creative work with PCIe® 4.0 x4 and PCIe® 5.0 x2 compatibility.

Stay on top of your game

The 990 EVO offers enhanced sequential read/write speeds up to 5,000/4,200 MB/s, and random read/write speeds up to 700K/800K IOPS, reaching 43% faster than the 970 EVO Plus 2TB. Wait less for games and access big files quick.

The light that starts from the left quickly flows to the right. The light flows into the SSD installed inside the computer, and the 990EVO appears.Next, the phrase "Sequential read speed up to 5,000 MB/s" appears in large letters, and underneath it, "Sequential writes Up to 4,200 MB/s", "Random reads Up to 700K IOPS", and "Random writes Up to 800K IOPS". Full speed information appears together.

* Sequential and random write performance was measured with Intelligent Turbo Write technology being activated. Intelligent Turbo Write operates only within a specific data transfer size. Performance may vary depending on SSD’s firmware, system hardware & configuration and other factors. For detailed information, please contact your local service center.* Test system configuration: AMD Ryzen9 7950x 16-Core Processor CPU@4.5GHz, DDR5 4800MHz 16GBx2 (PC5-38400), OS-Windows 11 Pro 64bit, Chipset - ASRock X670E Taichi* To maximize the performance of the 990 EVO, please check whether your system supports PCIe® 4.0 or PCIe® 5.0 at the Intel or AMD website.* The product image may differ from the actual product.

Improved power efficiency

A 70% improvement in power efficiency over the previous model* helps to preserve battery life whilst using your computer. Plus, it supports Modern Standby, letting you stay connected to the internet and still receive notifications even in the low-power state.

* 970 EVO Plus sequential read/write - 636/550 MB/Watt, 990 EVO sequential read/write – 1,020/933 MB/Watt based on internal test result of 1TB capacity model.* For detailed information about Modern Standby, please visit microsoft website. https://learn.microsoft.com/en-us/windows-hardware/design/device-experiences/part-selection#ssd-storage

Smart thermal solution

The 990 EVO's heat spreader label helps to control the temperature of the NAND chip. Samsung's cutting-edge thermal control algorithm, paired with Dynamic Thermal Guard, ensures both consistent and reliable performance. Keep your performance red-hot, not your drive.

Versatile to suit your needs

Designed to meet the demands of gaming, business and creative work. Supported by the latest PCIe® 4.0 x4 and PCIe® 5.0 x2 interfaces, it offers flexibility for current computing and what's to come. Stay on top with this all-around player.

Versatile to suit your needs

Samsung Magician software

Make your SSD works like magic. Samsung Magician software's optimisation tools ensure the best SSD performance. It's the safe and easy way to migrate all your data for a Samsung SSD upgrade. Protect valuable data, monitor drive health, and get the latest firmware updates.

* For detailed information, please visit Samsung Magician software website. https://semiconductor.samsung.com/consumer-storage/magician/

Bringing innovations to life

For decades, Samsung’s NAND flash memory has powered groundbreaking technologies that have changed every part of our daily lives. This NAND flash technology also powers our consumer SSDs, making room for the next big push of innovation.

Specifications

Interface PCIe® 4.0 x4 / 5.0 x2 NVMe™ 2.0
Sequential Read Up to 5,000 MB/s * Performance may vary based on system hardware & configuration
Sequential Write Up to 4,200 MB/s * Performance may vary based on system hardware & configuration
Warranty 5-year Limited Warrantyor 1200 TBW Limited Warranty
Application Client PCs
Weight Max 9.0g Weight

General Feature

Application Client PCs
Capacity 2,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor M.2 (2280)
Interface PCIe® 4.0 x4 / 5.0 x2 NVMe™ 2.0
Dimension (WxHxD) 80 x 22 x 2.38 mm
Weight Max 9.0g Weight
Storage Memory Samsung V-NAND TLC
Controller Samsung in-house Controller
Cache Memory HMB(Host Memory Buffer)

Special Feature

TRIM Support Supported
S.M.A.R.T Support Supported
GC (Garbage Collection) Auto Garbage Collection Algorithm
Encryption Support AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support Not supported
Device Sleep Mode Support Yes

Performance

Sequential Read Up to 5,000 MB/s * Performance may vary based on system hardware & configuration
Sequential Write Up to 4,200 MB/s * Performance may vary based on system hardware & configuration
Random Read (4 KB, QD32) Up to 700,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD32) Up to 800,000 IOPS * Performance may vary based on system hardware & configuration
Random Read (4 KB, QD1) Up to 20,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4 KB, QD1) Up to 90,000 IOPS * Performance may vary based on system hardware & configuration

Environment

Average Power Consumption (system level) *Average: Read 5.5 W / Write 4.7 W* Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle) Typical 60 mW * Actual power consumption may vary depending on system hardware & configuration
Power Consumption (Device Sleep) Typical 5 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage 3.3 V ± 5 % Allowable voltage
Reliability (MTBF) 1.5 Million Hours Reliability (MTBF)
Operating Temperature 0 - 70 ℃ Operating Temperature
Shock 1,500 G & 0.5 ms (Half sine)

Accessories

Installation Kit Not Available

Software

Management SW Magician Software for SSD management

Warranty

5-year Limited Warrantyor 1200 TBW Limited Warranty

Hide All Specs

Support

Find answers to the questions you have about our products

FAQ

Where can I download the Samsung Data Migration Tool to back up my data to an SSD drive?
